Quick Details
-
Fork Length:
-
0
-
Fork Width:
-
0
-
Overall Dimensions:
-
1995*1100*1280mm
-
Weight (KG):
-
1360 kg
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Hyster
-
Fork Length:
-
0
-
Fork Width:
-
0
-
Overall Dimensions:
-
1995*1100*1280mm
-
Weight (KG):
-
1360 kg
| Model | T6.0UT | |
| Driving Mode | Electric machinery48V AC | |
| Mode of driving | Riding type | |
| Rated towing weight (60 minutes) | kg | 6000 |
| Rated tractive effort (60 minutes) | N/kg | 1500/150 |
| Max. tractive effort (5 minutes) | N/kg | 6000/600 |
| Vehicle weight (including battery) | kg | 1360 |
| Axle load, no load front/rear | kg | 450/910 |
| Number of tires Front/Rear | X=Driving wheel | 1/2X |
| Tyre size front | Solid tire | 15*4.5 |
| Tyre size rear | Solid tire | 4.00-8 |
| Wheelbase | L1(mm) | 1280 |
| Rear overhang | L2(mm) | 500 |
| Wheel track front | mm | |
| Wheel track rear | W1(mm) | 946 |
| Seat height | h4(mm) | 910 |
| Height of hook center from the ground | h1/h2/h3(mm) | 295/370/440 |
| Overall length | L(mm) | 1995 |
| Overall width | W(mm) | 1100 |
| Overall height (excluding cab) | H | 1280 |
| Angle of approach | a1(°) | ≥45 |
| Departure Angle | a2(°) | ≥40 |
| Mini. ground clearance | X(mm) | 90 |
| Turning Radius | Wa(mm) | 1650 |
| Travel Speed No Load | km/h | 14.5 |
| Travel Speed Full Load | km/h | 8 |
| Max. Gradeability Full Load/No Load | % | 7/15 |
| Service brake/parking brake | Hydraulic/manual | |
| Power of driving motor | KW | 5.6 |
| Steering motor power (option) | KW | 0.6 |
| Battery voltage/rated capacity | V/Ah | 48/400 |
| Battery Weight | kg | 680 |
| Noise in driver's ear | dB(A) | <68 |
- Provide Professional advice for each customer's question,consult the sea freight and other related fees for the des-ignated port. Let customers know every detail before placing an order.
- We are all thinking for customers, through customer visits,telephone and fax to customers to understand our compa-ny's product features and service functions, to grasp the customer's current situation.
- We needs as much as possible, retional use of resources to guide customers, feasibility analysis and positioning according to customer needs and Investment plans to provide the best equipment configuration.
Q1: How long is the warranty of forklift from Yantai YICHA ?
A1: Products provided by Yantai Yicha enjoy free technical support for life and a one-year or 1000-hour working warranty period .
Q2:Can we print our logo/website/company name on products?
A2:Yes.
Q3:What's the lead time for regular order?
A3: Conventional products arrive at the port in 3-7 days, and non-standard customized products arrive at the port in 20-30 working days.
Q4: What are the strengths of your company?
A4: We have been in the industry for 18 years, we are very familiar with various Chinese brands, and have good resources to provide you with the most cost-effective products.
Q5:Do you inspect the finished products?
A5:Yes, each step of production and finished products will be came out inspection by QC department before shipping.
