Quick Details
-
Model Number:
-
G-1000
-
Voltage:
-
12v/24V/48V/96V
-
Certification:
-
CE
-
Rated output power:
-
1000w
-
Rated speed:
-
450rpm
-
Rated Voltage:
-
12v/24V/48V/96V
-
Rated Current:
-
8.1A/4.1A
-
Efficiency:
-
>95%
-
Start torque:
-
<1.6OΩ
-
Shaft Material:
-
stainless steel
-
Rotor:
-
Permenent Magnet Generator
-
Phase:
-
3 phase
-
Application:
-
Electricity Generation
Quick Details
-
Power:
-
1000w
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
FLTXNY
-
Model Number:
-
G-1000
-
Voltage:
-
12v/24V/48V/96V
-
Certification:
-
CE
-
Rated output power:
-
1000w
-
Rated speed:
-
450rpm
-
Rated Voltage:
-
12v/24V/48V/96V
-
Rated Current:
-
8.1A/4.1A
-
Efficiency:
-
>95%
-
Start torque:
-
<1.6OΩ
-
Shaft Material:
-
stainless steel
-
Rotor:
-
Permenent Magnet Generator
-
Phase:
-
3 phase
-
Application:
-
Electricity Generation
2.low start-up torque, wind energy utilization high;
3.small size, beautiful appearance, low vibration
4. human friendly design, easy installation, maintenance and repair.
5.permanent magnet generator rotor using patented alternator, together with the special stator design, effectively reduce the
generation of resistance torque, while allowing more wind turbines and generator has good matching characteristics, the unit runs
reliability
|
Model
|
G-1000
|
|
|
|
|||
|
Rated power
|
1000W
|
|
|
|
|||
|
Maximum power
|
1250W
|
|
|
|
|||
|
Rated speed
|
450rpm
|
|
|
|
|||
|
Rated voltage
|
12V/24v/48V AC
|
|
|
|
|||
|
Rated Current
|
8.1A/4.1A
|
|
|
|
|||
|
Efficiency
|
>95%
|
|
|
|
|||
|
Resistance (Line-Line)
|
<1.6
|
|
|
|
|||
|
Winding type
|
Y
|
|
|
|
|||
|
Insulation Resistance
|
100Mohm Min(500VDC)
|
|
|
|
|||
|
Leakage level
|
<5ma
|
|
|
|
|||
|
Start torque
|
<0.1
|
|
|
|
|||
|
Phase
|
Three Phase
|
|
|
|
|||
|
Structure
|
Outer Rotor
|
|
|
|
|||
|
Stator
|
Coreless
|
|
|
|
|||
|
Rotor
|
Permenent Magnet Generator(Outer Rotor)
|
|
|
|
|||
|
Dimension(height*shaft*diameter)
|
185*135*190
|
|
|
|
|||
|
Net Weight
|
18kg
|
|
|
|
|||
|
Housing Material
|
Aluminum(Alloy)
|
|
|
|
|||
|
Shaft Material
|
Stainless Steel
|
|
|
|
|||
