- Product Details
- {{item.text}}
Quick Details
-
Color:
-
Blue
-
Material:
-
Plastic
-
Applicatioon:
-
Water storage
-
Label:
-
Private/EWP
-
Packing:
-
Carton
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Weight (KG):
-
10 kg
-
Product name:
-
Water Storage Tank
-
Color:
-
Blue
-
Material:
-
Plastic
-
Applicatioon:
-
Water storage
-
Label:
-
Private/EWP
-
Packing:
-
Carton
Products Description
Features
1. Pressure tanks are made of high performance Composite material with FRP filament winding. All pressure tanks are 100%
corrosion resistant.
2. Full line of pressure tanks from 6” to 63” in diameter and from 10” to 86” in height.
3. Liner wall thickness available from 0.15” (3.0 mm) to 0.3” (7.6 mm) corresponding to the tank diameter.Certifications: NSF-61 listed sealing gasket ISO-9001 certified quality Testing: 100% hydraulic tests before delivery
corrosion resistant.
2. Full line of pressure tanks from 6” to 63” in diameter and from 10” to 86” in height.
3. Liner wall thickness available from 0.15” (3.0 mm) to 0.3” (7.6 mm) corresponding to the tank diameter.Certifications: NSF-61 listed sealing gasket ISO-9001 certified quality Testing: 100% hydraulic tests before delivery
Operating Condition:
Operating Pressure: 150psi (10.5 bars) Operating Temperature: 120.F (49°C), 50.F(65°C) for Flange Tanks
Certificate:
NSF and CE listed
Operating Pressure: 150psi (10.5 bars) Operating Temperature: 120.F (49°C), 50.F(65°C) for Flange Tanks
Certificate:
NSF and CE listed
Detailed Images
|
Tank Size
|
Volume
|
Opening
|
|
Base
|
Color
|
|
|
|
(Liters)
|
Top
|
Bottom
|
|
|
|
|
7*13
|
6.3
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
7*17
|
8.5
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
7*35
|
19.1
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
7*44
|
24.3
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
8*17
|
10.5
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
8*35
|
23.6
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
8*44
|
31.3
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
9*17
|
13.2
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
9*35
|
31.6
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
9*42
|
38.5
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
9*48
|
44.6
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
10*17
|
16.5
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
10*35
|
38.3
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
10*44
|
49.5
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
10*54
|
61.9
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
12*48
|
77.3
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
12*52
|
84.8
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
13*54
|
103.6
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
14*65
|
145.6
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
14*65
|
145.6
|
4"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
16*65
|
187.7
|
2.5"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
16*65
|
187.7
|
4"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
16*65
|
187.7
|
4"
|
4"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
18*65
|
249
|
4"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
18*65
|
249
|
4"
|
4"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
21*62
|
326
|
4"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
21*62
|
326
|
4"
|
4"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
24*72
|
471
|
4"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
24*72
|
471
|
4"
|
4"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
30*72
|
758
|
4"
|
|
Standard
|
Natural/blue/grey etc.
|
|
|
30*72
|
758
|
4"
|
4"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
30*72
|
717
|
6"
|
6"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
36*72
|
1023
|
6"
|
6"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
42*72
|
1389
|
6"
|
6"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
48*72
|
1743
|
6"
|
6"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
63*70
|
2580
|
6"
|
6"
|
Tripod
|
Natural/blue/grey etc.
|
|
|
63*83
|
3150
|
6"
|
6"
|
Tripod
|
Natural/blue/grey etc.
|
|
Packing and Delivery
Solid Packing
Small FRP tanks will be packed in individual cartons, and bigger size will be held on a pallets.
Packing will be enhanced for international shipping.
Packing will be enhanced for international shipping.
