Quick Details
-
Rated Lifting Moment:
-
Contact supplier
-
Span:
-
Contact supplier
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
zoomlion
-
Weight (KG):
-
5000 kg
-
Color:
-
Optional
-
Free height:
-
34.9m
-
Mast section size:
-
1800*1800*2800mm
-
Hoisting capacity at jib tip:
-
1.3t
-
Maximum lifting moment:
-
63 t.m
-
Min.working radius:
-
2.5m
-
Hoisting mechanism:
-
H18SP13-400
-
Slewing mechanism:
-
HR55.130
-
Trolleying mechanism:
-
BE24B
-
Certification:
-
iso, ce
Quick Details
-
Rated Loading Capacity:
-
5ton
-
Max. Lifting Height:
-
50m
-
Application:
-
construction
-
Rated Lifting Moment:
-
Contact supplier
-
Span:
-
Contact supplier
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
zoomlion
-
Weight (KG):
-
5000 kg
-
Color:
-
Optional
-
Free height:
-
34.9m
-
Mast section size:
-
1800*1800*2800mm
-
Hoisting capacity at jib tip:
-
1.3t
-
Maximum lifting moment:
-
63 t.m
-
Min.working radius:
-
2.5m
-
Hoisting mechanism:
-
H18SP13-400
-
Slewing mechanism:
-
HR55.130
-
Trolleying mechanism:
-
BE24B
-
Certification:
-
iso, ce
Tower Crane Fixing Angle TC5013A-5 Tower Crane with 50m Lifting Capacity
Acntruck International is a leading Chinese construction machinery exporter, located in the downtown of Shanghai City.
Since our company was founded, we continually introduce top Chinese construction machinery enterprises and their products to international markets. We not only make more international customers know and approbate our products, but also gradually build up friendship with construction machinery customers all over the world.
With a balanced and diversified approach towards the ever changing market scenario in perfect combination with strategic management and organic growth, Acntruck International has emerged as a renowned exporter of a wide range of top Chinese Construction Machinery.
↓↓↓ Details Parameter ↓↓↓
1. Performance parameters of TC5013A-5: performance parameters and technical indexes reach both domestic and international advanced level.
• Max. jib length: 50m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length is 30 meters.
• Max. lifting capacity 5t;
• Hoisting capacity at jib tip: 1.3t;
• Maximum lifting moment 63 t.m
• Hoisting mechanism: H18SP13-400; power: 18/18/5 kW; rope capacity: 400m;
• Slewing mechanism: HR55.130; power: 5.5 kW;
• Trolleying mechanism: BE24B; power: 2.4/1.5kW.
2. Electrical control system
With PLC control, the electrical control system enjoys better reliability and safety. Produced by professional manufacturers with advanced foreign technology, the electrical elements feature service lives that are 3 or 4 times longer than that of domestic products, less faults, easy maintenance and repair as well as reliable operation.
3. Technical features
• The crane boasts of multiple operation modes and wide application;
• The complete machine adopts internationally well-received beautiful shape;
• The crane features high working speed and excellent speed regulation performance. Stepless speed regulation by frequency control, the world's most advanced solution, is adopted for the trolleying mechanism and slewing mechanism, thus ensuring more stable and reliable operation ;
• The cab is independently installed externally with good vision and large inner space, thus offering a good working environment for operators;
• A variety of safety devices are equipped, which are all mechanical or mechatronic products that are applicable to severe working conditions, so as to ensure the tower crane's reliable operation.
| Rated lifting moment(t.m) | 63 | ||||||
| Max.lifting height(m) | Free-standing stationary crane | 34.9 | |||||
| Anchored crane | 175 | ||||||
| Working radius(m) | Max.working radius | 50 | |||||
| Min.working radius | 2.5 | ||||||
| Max.lifting capacity(t) | 4 | ||||||
| Hoisting mechanism | Ropefall | α=2.5 | α=5 | ||||
| Speed(m/min) | 65 | 32.5 | 9.7 | 32.5 | 16.25 | 4.85 | |
| Lifting weight(t) | 1.25 | 2.5 | 2.5 | 2.5 | 5 | 5 | |
| Power(kW) | 18/18/5 | ||||||
| Slewing mechanism | Speed(m/min) | 0~0.6 | |||||
| Power(kW) | 5.5 | ||||||
| Trolleying mechanism | Speed(r/min) | 40/20 | |||||
| Power(kW) | 2.4/1.5 | ||||||
Pinky Zhou
Whatsapp /Mobile / Wechat: +86 18851721561
E-mail: pinky@)acntruck.com
Facebook: https://www.facebook.com/pinky.zhou625/
↓↓↓ Pictures about Product ↓↓↓
