Quick Details
-
Place of Origin:
-
Jiangxi, China
-
Brand Name:
-
Steadywin
-
Model Number:
-
PM100
-
Torque:
-
1.6N.M
-
Color:
-
Black
-
Size:
-
100*37mm
-
Certification:
-
CCC
Quick Details
-
Speed(RPM):
-
130rpm
-
Continuous Current(A):
-
1.75A
-
Efficiency:
-
Ie 3
-
Place of Origin:
-
Jiangxi, China
-
Brand Name:
-
Steadywin
-
Model Number:
-
PM100
-
Torque:
-
1.6N.M
-
Color:
-
Black
-
Size:
-
100*37mm
-
Certification:
-
CCC
Product Description
Specification
|
Item Name
|
|
PM100
|
|
Nominal Voltage
|
V
|
24
|
|
Nominal Current
|
A
|
1.75
|
|
Nominal Torque
|
N.M
|
1.60
|
|
Nominal Speed
|
rpm
|
130
|
|
Max Speed
|
rpm
|
290
|
|
Stall Torque
|
N.M
|
2.00
|
|
Stall Current
|
A
|
3.00
|
|
Phase to Phase Resitance
|
Ω
|
3.00
|
|
Phase to Phase Indutance
|
mH
|
31.50
|
|
Speed Constant
|
rpm/V
|
11
|
|
Torque Constant
|
N.M/A
|
1.13
|
|
Rotor Inertia
|
gcm^2
|
2860
|
|
Number of Pole Pairs
|
|
21
|
|
Motor Weight
|
g
|
472
|
|
Working Temperature
|
°C
|
-20°C~80°C
|
|
Max Demagnetize Temperature
|
°C
|
120°C
|
|
Encoder Type
|
|
AS5048A/AS5600
|
