Technical Information
◇Material: Stainless Steel Grade 304 Or 316
◇Coating: PVC
◇Working Temp.: -40℃ to 85℃
◇Description: Black Band with Metallic Buckle
◇Flammability: Fireproof
◇Other Properties: UV-resistant
Product Feature
◇Metallic buckle helps to distinguish from black nylon cable ties.
◇PVC coated band is thicker and softer, than polyester coated band.
◇Coated band provide additional edge protection, prevent the corrosion between dissimilar metals.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Tolerabce
-
Model Number:
-
MGC-5.6*350
-
Color:
-
Black
-
Product name:
-
Stainless Steel Banding Strap
-
Feature:
-
Self-locking Fastening
-
Size:
-
5.6*350
-
Packing:
-
100pcs/bag
-
Certification:
-
CE ROHS
-
Application:
-
Electrical Applications
-
Usage:
-
Bunding Wires
-
Length:
-
350
Quick Details
-
Type:
-
stainless steel band
-
Material:
-
stainless steel
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Tolerabce
-
Model Number:
-
MGC-5.6*350
-
Color:
-
Black
-
Product name:
-
Stainless Steel Banding Strap
-
Feature:
-
Self-locking Fastening
-
Size:
-
5.6*350
-
Packing:
-
100pcs/bag
-
Certification:
-
CE ROHS
-
Application:
-
Electrical Applications
-
Usage:
-
Bunding Wires
-
Length:
-
350
Product Description
Ball-Lock PVC Coated Ties
|
Name：
|
Self-Locking Type Stainless Steel Cable Tie
|
|
Material:
|
#304 #316 stainless steel
|
|
Structure:
|
Self locking, ball bearing mechanism for quick and easy installation, either by hand
|
|
Working temperature:
|
-80℃-500℃
|
|
Length:
|
All lengths are available
|
|
Feature:
|
High tensile strength Rust poof Non-flammability Anti corrosion High resistance to aceticacid,alkaliacid,suiphuric acid, acorrode etc
|
|
Certificate:
|
RoHS, CE
|
|
Usage:
|
First, the cable is bundled in a stainless steel cable tie; Next, the tail of the stainless steel band is clamped by the tool;
Finally, tighten with tool |
|
Application:
|
Shipbuilding,port,machinery,automobiles,aviation,electricity, communication selectronics,nuclear power,interurban locomotive and other industries
|
|
Delivery time:
|
7-15 days (Depend on your order quantity) after confirm order.
|
|
Payment terms:
|
T/T,Western Union,L/C ,PayPal
|
Specification:
|
规格型号
Item No. |
Width
|
Length
|
|
Thickness
|
Max.Bundle Dia
|
|
Min.Bundle Dia
|
Min.Tensile Strength
|
||
|
|
mm/inch
|
mm
|
inch
|
mm/inch
|
mm
|
inch
|
mm/inch
|
N/IBS
|
||
|
NGC-5.6*150
|
5.6/0.22
|
150
|
5.9
|
|
37
|
1.46
|
12.7/0.5
|
350/80
|
||
|
NGC-5.6*200
|
|
200
|
79
|
|
50
|
1.94
|
|
|
||
|
NGC-5.6*250
|
|
250
|
9.8
|
|
63
|
2.48
|
|
|
||
|
NGC-5.6*350
|
|
350
|
13.8
|
|
89
|
3.5
|
|
|
||
|
NGC-5.6*450
|
|
450
|
17.7
|
|
115
|
4.53
|
|
|
||
|
NGC-5.6*600
|
|
600
|
23.6
|
|
154
|
6.06
|
|
|
||
|
NGC-56*750
|
|
750
|
29.5
|
|
178
|
7.01
|
|
|
||
|
NGC-56*900
|
|
900
|
35.4
|
|
229
|
9.02
|
|
|
||
|
MGC-9.0*200
|
9/0.35
|
200
|
7.9
|
|
52
|
2.05
|
25.4/1
|
445/100
|
||
|
MGC-9.D*250
|
|
250
|
9.8
|
|
65
|
256
|
|
|
||
|
MGC-9.0*300
|
|
300
|
11.8
|
|
78
|
3.07
|
|
|
||
|
MGC-9.D*400
|
|
400
|
15.7
|
|
102
|
4.02
|
|
|
||
|
MGC-9.D*500
|
|
500
|
19.7
|
|
128
|
5.04
|
|
|
||
|
MGC-9.0*650
|
|
650
|
25.6
|
|
165
|
6.5
|
|
|
||
|
MGC-9.0*800
|
|
800
|
31.5
|
|
204
|
8.03
|
|
|
||
|
MGC-9.0*1000
|
|
1000
|
39.4
|
|
254
|
10
|
|
|
||
|
MGC-16*350
|
16/0.63
|
350
|
13.8
|
1.2/0.047
|
89
|
3.5
|
25.4/1
|
889/200
|
||
|
MGC-16*450
|
|
450
|
17.7
|
|
115
|
4.53
|
|
|
||
|
MGC-16*550
|
|
550
|
21.7
|
|
141
|
5.55
|
|
|
||
|
MGC-16*700
|
|
700
|
27.6
|
|
179
|
7.05
|
|
|
||
|
MGC-16*850
|
|
850
|
33.5
|
|
216
|
8.5
|
|
|
||
|
MGC-16*1100
|
|
1100
|
13.3
|
|
280
|
11.02
|
|
|
||
Application
Why Choose Us
COMPANY PROFILE
Zhejiang Tolerance Electrical Co. Ltd. is a professional manufacturer of wiring accessories factory. After builting our own factory, Tolerance focuses on the R & D, production and sale various kinds of wiring accessories all the time. The main products includes cable clips, expand plugs, self adhesive tie mount, saddle type tie mount, cable glands, spiral wrapping bands, stainless steel ties and so on. Our products are mainly applied in housing decoration wiring, wiring of building engineering, sets of electrical wiring, wiring of the shipbuilding industry, communication engineering wiring, light industry and heavy industry,meanwhile, the quality of our products enjoy great popularity at home and abroad. Tolerance will countine to improve the quality and service of products and commit to innovate technology in oreder to meet with the different requirement from globle market. In the future, our company is dedicating in carrying forward the spirit of “Tolerance,for wisdom and different”.
Exhibition
Certifications
FAQ
Q1: Could I Put My Own Logo On It?
A1: Sure, of course, we are a professional manufacturer and have over 10 years OEM experience,
customer;s logo can be made by laser, engraved, embossed, transfer printing etc.
customer;s logo can be made by laser, engraved, embossed, transfer printing etc.
Q2: What's the delivery time?
A2: Normally,3-15days after order and payment confirmation. Actually, it will depend on your orderquality.
Q3: What's your terms of payment?
A3: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
A3: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q4: How do you make our business long-term and good relationship?
A4: a. We keep good quality and competitice price to ensure our customers benefit; b. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
Q5: If we bought your products, but found quality problem, how to solve?
A5: After confirmed, if the quality problem is caused by us not for outer sector, we will compensate each piece to customer.
