Lecede P1 P3.91 P4 P10 Indoor Outdoor Ip65 Big Giant Grid Pixel Perimeter Store Module 64mm Panel Backdrop Transparent Film Led

Lecede P1 P3.91 P4 P10 Indoor Outdoor Ip65 Big Giant Grid Pixel Perimeter Store Module 64mm Panel Backdrop Transparent Film Led

FOB Reference Price: Get Latest Price

≥1 Square meters

US $330

≥20 Square meters

US $315

≥50 Square meters

US $292

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Color:: Full Color

Panel Size:: 1000*500

Place of Origin:: Guangdong, China

Model Number:: T

use:: Concerts, Events, Stage Background Video Wall

HS Code:: 8528591090

Resolution:: 3840

Product name:: Film Clear Led Screen

Warranty:: 5 Years

Feature:: With not falling off side lock&seamless side lock

Brightness:: 700-5500 nits

Color Temperature:: 3200~ 9500K

Refresh Rate:: 1920~ 3840 Hz

Average Power Consumption:: 300 W/㎡

Cabinet Material:: Diecasting Aluminum

Keyword:: Easy Installation DJ Event Stage Background Rental Led Video Wall

Certificate:: CE ROHS FCC CCC ISO9001

Pixel Pitch:: 10mm

Quick Details

Application:: Indoor, Outdoor

Type:: LED

Brand Name:: Lecede

Color:: Full Color

Panel Size:: 1000*500

Place of Origin:: Guangdong, China

Model Number:: T

use:: Concerts, Events, Stage Background Video Wall

HS Code:: 8528591090

Resolution:: 3840

Product name:: Film Clear Led Screen

Warranty:: 5 Years

Feature:: With not falling off side lock&seamless side lock

Brightness:: 700-5500 nits

Color Temperature:: 3200~ 9500K

Refresh Rate:: 1920~ 3840 Hz

Average Power Consumption:: 300 W/㎡

Cabinet Material:: Diecasting Aluminum

Keyword:: Easy Installation DJ Event Stage Background Rental Led Video Wall

Certificate:: CE ROHS FCC CCC ISO9001

Pixel Pitch:: 10mm

Projects

Product: T10

Application: Advertising
Location: DE
Screen Size: 6*3m
Screen Resolution: 165888dots
Pixel Pitch: P10.42

Product: T10
Application: Advertisement
Location: USA
Screen Size: 4*3m
Screen Resolution: 110592dots
Pixel Pitch: P10.42

Product: T2.8
Application: 4S exhibition
Location: USA
Screen Size: 9*3mm
Screen Resolution: 167204dots
Pixel Pitch: P2.84

Product: T3.9

Application: Shopping
Location: UK
Screen Size: 15*9m
Screen Resolution: 4423680dots
Pixel Pitch: P3.91

Product: T15
Application: Shopping Mall
Location: Thailand
Screen Size: 16*6m
Screen Resolution: 393216dots
Pixel Pitch: P15.63

View More>>

Products Description

Lecede P1 P3.91 P4 P10 Indoor Outdoor Ip65 Big Giant Grid Pixel Perimeter Store Module 64mm Panel Backdrop Transparent Film Led

Model No.	T2.6	T2.8	T3.9	T10	T15
Pixel Pitch (mm)	W2.6-H 5.2	W2.84-H5.62	W3.91-H7.82	10.42	15.63
LED Type	SMD 1921	SMD 1921	SMD 1921	SMD 1921	SMD 1921
Pixel Density (pixel/㎡)	73728	61952	32768	9216	4096
Cabinet Dimension (W*H) (mm)	1000x 500	1000x 500	1000x 500	1000x 500	1000x 500
Cabinet Resolution (W*H) (Pixel)	384x 96	352x 88	256x 64	96x 48	64x 32
Cabinet Material	Aluminum Extrusion
Cabinet Weight (Kg)	6.5	6.5	6.5	6.5	6.5
Cabinet Weight (Kg)	12	11	8	2	Static

Best Viewing Distance (m)	3	3	5	10	15
Brightness (nits)	1500~ 5000	1500~ 5000	1200~ 5000	5000	5000
Transparency	60%	60%	70%	80%	85%
Ingress Protection (Front/Rear)	IP31
Viewing Angle	H:140° V:140°
Color Temperature	3200~ 9500K
Gray Level	14 bit
Max Power Consumption (W/㎡)	800
Average Power Consumption (W/㎡)	250
Refresh Rate (Hz)	1920~ 3840
Maintenance Method	Front/Rear Maintenance
Operating Temperature	-20°~ 60°
Operating Humidity	10%～95%RH
Input Voltage	AC110~ 220V±15%
MTBF (Hours)	50000
Life Time (Hours)	100000

Recommend Products

Buyer Feedback

Company Introduction

Shenzhen Lecede Opto electronics is a professional LED display manufacturer.Our products have passed the professional authority,such as CE, ROHS, FCC, CCC, ISO9001 certification and so on. We could ensure production capacity of 5000 square meters per month for LED displays with 8 modernized dust-free and static-free production lines,which consist of 20 new Panasonic high speed SMT machines, 2 large leadless reflow ovens.and 100 skilled workers. Our professional enaineers have 6 years' R&D experience in LED Display field Which is your strong backup and can help you to realize what you want Shenzhen Lecede products have been exported to 100 countries and regions with 5000 successful projects. such as America,Canada,Germany,France.New Zealand Russia. Spain. Switzerland. Turkey. Saudi Arabia Thailand Malaysia, Indonesia, South Korea, Mexico, Peru, Chile etc.

Shenzhen Lecede is always your reliable partner!

Exhibition

Packing & Delivery

FAQ

1. How much is the freight ?
The shipping cost is determined by the size of the screen, and the project information is informed by the inquiry.

2. What is Price per square meter of screen ?
Welcome to send us inquiry. Our professional sales engineers will provide suitable solutions.

3. Can I customize it ?
Of course. All the goods can be customized, we have a professional product development team, welcome to customize.

4. What is the warranty ?
5-8 years Warranty.

5. How many days for producing ?
1-3 days for inventory products and 10-15 days for customized products.

6. How to operate and use it ?
It can by controlled by PC and Smartphone very easily.
Welcome to inquiry for more information. We provide video guidance and remote assistance.
