Quick Details
-
Energy saving:
-
Yes
-
Color and logo:
-
as required
-
Surface treatment:
-
as required good paint finish
-
Long working life:
-
20-30years
-
Installation:
-
easy installation with English reference
-
Powder material:
-
mainly cement, fly ash etc
-
Accessories:
-
air-jet silo venting, pressure relief valve, butterfly valve, etc
-
Shape:
-
as required
-
After-sales Service Provided:
-
Online support
Quick Details
-
Place of Origin:
-
Fujian, China
-
Product name:
-
stainless steel silo manufacturers
-
Certification:
-
national patent
-
Energy saving:
-
Yes
-
Color and logo:
-
as required
-
Surface treatment:
-
as required good paint finish
-
Long working life:
-
20-30years
-
Installation:
-
easy installation with English reference
-
Powder material:
-
mainly cement, fly ash etc
-
Accessories:
-
air-jet silo venting, pressure relief valve, butterfly valve, etc
-
Shape:
-
as required
-
After-sales Service Provided:
-
Online support
Bolted coffee bean stainless steel silo manufacturers
stainless steel silo manufacturers
Product introduction
Subject:
silos, sheet silos, steel silos, cement silo, assembled silo, bolted-type silo, powder silo, concrete batching plant silo, high quality silo, competitive price silo, 50T-2000T silo, fly ash silo.
Used for:
Luwei bolted-type silo is used for storing bulk materials such as grains, cement, powder, lime, gypsum, fly ash, different binder materials, gravel, limestone, sand and different chippings.
Application:
Luwei bolted-type silo is mainly used in many areas, such as construction material, chemical engineering, energy resources, environmental protection and foodstuff, like loading and unloading plants, dosing-weighing and mixing plants, batching plant etc..
Product features
1) Various capacity and customized silo. The capacity of bolted-type silo ranges from 50T to 2000T flexible. All the data of silos is calculated by TJU (Tongji University), it considers strength of silo, resistance coefficient of the typhoon and bending resistance coefficient.
Technical index (just for reference):
|
Serial number |
Model and size |
Diameter (mm) |
number of layers |
Leg distance (mm) |
Theoretical capacity (M3) |
|
1 |
PG50T |
3100 |
3 |
2020 |
40.67 |
|
2 |
PG60T |
3100 |
4 |
2020 |
52.13 |
|
3 |
PG100T |
3100 |
7 |
2020 |
86.52 |
|
4 |
PG150T |
3300/3800 |
6/8 |
2180/2570 |
111.74/114.96 |
|
5 |
PG200T |
4500 |
6 |
3010 |
164.27 |
|
6 |
PG300T |
5000 |
7 |
3290 |
234.85 |
|
7 |
PG400T |
5700 |
8 |
2640 |
348.14 |
|
8 |
PG500T |
6500 |
8 |
3015 |
458.36 |
|
9 |
PG800T |
8000 |
8 |
3660 |
700 |
2) Fully equipped factory. With mature special cutting and drilling technology, all parts are specially cleaned on the surface, and then well painted both inside and outside.
3) Professional packing and loading. All parts of silo can be packing into bundles with short loading time and little space. Whatever large size of silo, it can be shipped into container by sea all over the world.
The container require for transportation (for reference):
4) Easy assembly. All the parts of silo can be well assembled with the help of English Installation Instruction Program. The construction will be safe and efficient.
Q1:What are the After-Sales service you provide?
A:We can provide engineers available to service machinery overseas.
Q2;What is you company?
A:We are a factory.
Q3:What is your terms of payment ?
A: 30% TT in advance, 70% balance by sight LC.
