Quick Details
-
Structure:
-
FILM+Glass
-
Cover Glass Dimension:
-
164.7*103.7±0.3
-
Size:
-
7inch
-
Warranty:
-
12 Months
-
Application:
-
Industrial Application
-
Interface:
-
VGA
-
Operating System:
-
XP Win7 8 Android Linux
-
Product name:
-
Touch Screen Panel
Quick Details
-
Type:
-
Resistive
-
Brand Name:
-
wiwo
-
Place of Origin:
-
Fujian, China
-
Structure:
-
FILM+Glass
-
Cover Glass Dimension:
-
164.7*103.7±0.3
-
Size:
-
7inch
-
Warranty:
-
12 Months
-
Application:
-
Industrial Application
-
Interface:
-
VGA
-
Operating System:
-
XP Win7 8 Android Linux
-
Product name:
-
Touch Screen Panel
Product Description
| 7 Inch Projected Resicitive TouchPanel | |
| Model Number | CRP070GF0414 |
| Type | PCAP |
| Structure | FILM+Glass |
| Cover Glass Dimension | 164.7×103.7±0.3MM |
| Sensor Size | 725.06±0.2*424.84±0.2*1.1±0.1MM |
| Cover Lens VA | 699.9±0.15*394±0.15MM |
| Resistance |
Film side: 100Ω~500Ω
Glass side:400Ω~1100Ω |
| Surface Hardness | ≥3H |
| Interface of CTP | I2C |
| Transparency | ≥78% |
| Touch Points | 5-10 points |
| Operation temperature | —20℃~+70℃ |
| Storage Temperature | —25℃~+75℃ |
| High temperature storage | 70℃, 240hr |
| Low temperature storage | —20℃, 240hr |
| Total Thickness | 1.4±0.15MM |
| Touch Accuracy | ±2MM |
| Linearity | ±2MM |
| MOQ | 10pcs |
| Sample Lead Time | 12 working days |
| Mass Production Lead Time | 2-4 weeks normally, it depends on your order quantity |
| OEM/ODM | we can make this product as per your design and put your logo on |
| Payment Terms | sample: by paypal or western union mass production order: T/T to our company bank account, 50% deposit, 50% balance before shipment |
| Warranty | 12 months |
| Package | plastic tray or anti static foam or paper card or vacuum bag or carton |
