STA pyrex 3.3 thinner thickness borosilicate glass tube

STA pyrex 3.3 thinner thickness borosilicate glass tube

FOB Reference Price: Get Latest Price

≥1000 Pieces

US $0.15

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model Number:: STA-BG04

Size:: as customized

Thickness:: 0.5-10mm

thickness:: 0.5mm-10mm

shape:: as customiazed

Quick Details

Type:: Sandblasted Glass

Place of Origin:: Henan, China

Brand Name:: STA

Model Number:: STA-BG04

Size:: as customized

Thickness:: 0.5-10mm

thickness:: 0.5mm-10mm

shape:: as customiazed

STA pyrex 3.3 thinner thickness borosilicate glass tube

Description:

Borosilicate glass tubing and rods made by us are well-known for their stability and pressure resistance, good workability and high thermal shock resistance. We have a very low rate of thermal expansion, which makes it an excellent material for laboratory glassware and for use in large-scale technological plants in the chemical apparatus industry. Our products are resistant to corrosion and remain absolutely neutral, even to aggressive chemicals, in nearly all fields of chemistry. This brings them a great advantage over other materials. Borosilicate glass is extremely resistant to water, acids, salt solutions, organic substances and halogens. Tubing, capillary and rod also have a high alkali resistance for physical and chemical properties.

Specifications:

Outer Diameter:30mm-400mm

Wall Thickness: 0.2mm- 10mm

standard length:1500mm or according per requirment

shape: round, flat, tringle, hexagon

Chemical Compositions and Physical and Chemical Properties

Chemical Compositions and Physical and Chemical Properties of Borosilicate Glass Type 3.3
composition	SiO2	B2O3	R2O	Al2O3	Fe2O3

weight%	80.3	13.0	4.2	2.4	0.035

Physics performance			Numerical Value		Unit

Medium coefficient if linear expansion			3.3±0.1		10 ^-6 K ^-1

Softening point			820±10		°C

Viscosity temperature			510±10		°C

Uper annealing temperature			560±10		°C

Thermal conductivity(20-100°C)			1.2		Wm ^-1 K ^-1

Temperature for the specific electrical resistance			240		°C

20°C Demsity ρ			2.23±0.02		g/cm ³

Endure water under 98 °C			ISO0719-HGB1		/

Endure water under 121 °C			ISO0720-HGA1		/

Acid-proof test			Na2O≤100		µg

Alkali-proof test			ISO0695		/

Working point: 1,260±20°C4)

Softening point: 820±10°C5)

Density at 20°C: 2.23g/cm²6)

Hydrolytic resistance at 98°C: ISO719-HGB17)

Hydrolytic resistance at 121°C: ISO720-HGA18)

Acid resistance class: ISO1776-1 9)

Alkali resistance class: ISO695-A2

Packing pictures

company pictuer

STA universe group is founded in 2001,dedicating to innovation ang creating a world famous brand.And provide various products for customers. We are a professional manufacturer of it for many 13 years,our products are exported to America ,Russia,European,Germany,Brazil,India and many other countries.

FAQ

1.What's your advantage to other suppliers?

We have our own factory which has more than 15years experience in producing and exporting alumina products,

we also have good business relations with some other factories.

Our goods’quality is high and price is reasonable and delivery is fast.

2.Can you produce as our drawing?

Yes,we have skilled technical engineer who can make products according to your photos or drawings.

3.After-Sale service:

1) 24 hours service for customers.

2) quality issue, we accept reworking if quality is not reach your requirements.

3) sample available for free

4) CE service acceptable. welcome your artwork.
