Quick Details
-
Function:
-
Remote Control, G-Sensor, Loop recording, APP Control, Build-in GPS, Build-in GSM, Emergency Accident Lock
-
Voltage:
-
9-36V
-
Working Temperature Range:
-
-20 - 70 ℃
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
MR9716-TGO
-
ITEM:
-
16Channels 1080P MDVR
-
Video Input:
-
AHD/Analog 1080P
-
Video Output:
-
CVBS&VGA/AHD
-
Alarm Input:
-
9
-
Power Input:
-
9-36V DC
-
Video Compression:
-
H.264/H.265
-
Storage:
-
Support 1x512G SD Card and 2x4TB HDD/SSD
-
4g GPS:
-
built-in
-
ipc:
-
built-in IPC Channel
-
Data Protection:
-
Yes
Quick Details
-
Car Fitment:
-
Universal
-
Angle:
-
150°
-
Resolution:
-
1080P
-
Function:
-
Remote Control, G-Sensor, Loop recording, APP Control, Build-in GPS, Build-in GSM, Emergency Accident Lock
-
Voltage:
-
9-36V
-
Working Temperature Range:
-
-20 - 70 ℃
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
MR9716-TGO
-
ITEM:
-
16Channels 1080P MDVR
-
Video Input:
-
AHD/Analog 1080P
-
Video Output:
-
CVBS&VGA/AHD
-
Alarm Input:
-
9
-
Power Input:
-
9-36V DC
-
Video Compression:
-
H.264/H.265
-
Storage:
-
Support 1x512G SD Card and 2x4TB HDD/SSD
-
4g GPS:
-
built-in
-
ipc:
-
built-in IPC Channel
-
Data Protection:
-
Yes
Specification
|
Video Compression Format
|
H265/H.264
|
|
ITEM
|
16Channels 1080P HDD Mobile DVR For Bus
|
|
Video Input
|
AHD/Analog 1080P
|
|
Video Output
|
CVBS&VGA
|
|
Alarm Input
|
9
|
|
Power Input
|
9-36V DC
|
|
Video Compression
|
H.264/H265
|
|
Storage
|
Support 1x512G SD Card and 2x4TB HDD/SSD
|
|
GPS 4G
|
built-in
|
|
IPC
|
built-in fourIPC Channel
|
|
Data Protection
|
Yes
|
Product Description
|
Device Parameter
|
Performance
|
|
Operating system
|
Embedded Linux OS
|
|
Operating language
|
Chinese/English
|
|
Operating interface
|
GUI, Support mouse
|
|
Password security
|
User password/Admin password
|
|
Video standard
|
PAL/NTSC
|
|
Video compression
|
H.265/H.264
|
|
Image resolution
|
1080P/720P/960H/D1/CIF
|
|
Playback quality
|
1080P/720P/960H/D1/CIF
|
|
Decoding ability
|
16ch 1080P real time
|
|
Recording quality
|
Class 1-6 optional
|
|
Image display
|
1、2、3、4、8、12 display optional
|
|
Audio Compression
|
G.711A、G.711U、G.726
|
|
Audio recording
|
Audio & Video synchronized recording
|
|
Recording mode
|
Automatic/Alarm
|
|
Audio bit rate
|
8KB/s
|
|
Storage media
|
SD card + HDD/SSD storage
|
|
Video inquiry
|
Inquiry by channel/Recording type/Alarm Type
|
|
Local playback
|
Local 8 CH
|
|
Upgrading mode
|
Manual/Automatic/Remote
|
|
Upgrading method
|
USB disk，SD card，network
|
|
AV input
|
8ch aviation interface
|
|
AV output
|
1ch VGA video output, 1ch aviation AV output
|
|
Alarm input
|
8 digital inputs
|
|
Alarm output
|
4 outputs
|
|
UART
|
1 LVTTL Level, 1 RS232
|
|
HDD/SSD
|
2 HDD/SSD (one up to 2TB) or
1 HDD/SSD (up to 4TB) |
|
SD card
|
1 SDXC High speed card
|
|
USB interface
|
1 USB 3.0 (support U disk/mouse)
|
|
CAN
|
2 CAN
|
|
Ignition input
|
1 ACC signal
|
|
LED Indication
|
PWR/RUN
|
|
Disk lock
|
1
|
|
Debug port
|
1
|
|
GNSS
|
GPS/BD/GLONASS
|
|
3G/4G
|
4G Netcom
|
|
WIFI
|
Optional WIFI module, 2.4GHz (optional)
|
|
IPC
|
6Pin M-12 aviation interface
|
|
Power input
|
9~36V DC
|
|
Power output
|
5V 300mA
|
|
Power consumption
|
Standby 4mA/12V
Power consumption: 18W |
|
Working temperature
|
-20 --- 70℃
|
|
Storage Size
|
1080P 0.726G/h/channel
720P 0.58G/h/channel |
|
Dimension
|
186mm*199mm*90mm
|
