Quick Details
-
Warranty(Year):
-
5-Year
-
Color Temperature(CCT):
-
5000, 3000K/4000K/5000K/6000K dimmable 1-10V
-
Input Voltage(V):
-
AC 100~277V 50-60HZ
-
Lamp Luminous Flux(lm):
-
42000LM
-
Working Temperature(℃):
-
-35 - 65
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Rayborn
-
Model Number:
-
RB-HB-300WU2
-
Input Voltage:
-
AC 100~277V dimmable 0-10V
-
Luminous Flux:
-
21000LM industrial led high bay lamp
-
Angle:
-
60/90/120degree beam angle
-
Power Factor:
-
>0.98 LED hibay
-
Color Rendering Index:
-
Ra>80 led ufo
-
IP Grade:
-
IP65 protections for industrial lamps
-
Power:
-
150W led high bay light ufo
-
LED Light Source:
-
SMD3030 high bay led light 150 watt
-
Power available:
-
100W 120W 150W 200W 240W 300W
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
140
-
Lamp Body Material:
-
Aluminum
-
Application:
-
Warehouse
-
Warranty(Year):
-
5-Year
-
Color Temperature(CCT):
-
5000, 3000K/4000K/5000K/6000K dimmable 1-10V
-
Input Voltage(V):
-
AC 100~277V 50-60HZ
-
Lamp Luminous Flux(lm):
-
42000LM
-
Working Temperature(℃):
-
-35 - 65
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Rayborn
-
Model Number:
-
RB-HB-300WU2
-
Input Voltage:
-
AC 100~277V dimmable 0-10V
-
Luminous Flux:
-
21000LM industrial led high bay lamp
-
Angle:
-
60/90/120degree beam angle
-
Power Factor:
-
>0.98 LED hibay
-
Color Rendering Index:
-
Ra>80 led ufo
-
IP Grade:
-
IP65 protections for industrial lamps
-
Power:
-
150W led high bay light ufo
-
LED Light Source:
-
SMD3030 high bay led light 150 watt
-
Power available:
-
100W 120W 150W 200W 240W 300W
180lm/W Anti Glare Industrial Factory Workshop UFO Bulb LED Highbay Light for Indoor Stadium Lighting 100W 150W 200W
Industrial LED High Bay Light With 5 Year Warranty (30w-500w )
| 150W UFO LED HIGH BAY | |||
| Item No.: | RB-HB-150WU2 | ||
| Input Voltage: | AC 100-277V | ||
| Freqency Range: | 50Hz~60Hz | ||
| LED Chip: | SMD3030 Chip | ||
| Power Driver: | Meanwell HBG | ||
| Power Factor: | >0.98 | ||
| Power Efficiency: | >92% | ||
| Luminous Efficiency: | 140LM/W | ||
| LED Power | 150W | ||
| LED QTY: | 196pcs 3030SMD | ||
| LED Working Voltage: | DC 42~48V | ||
| System Consumption: | 153W | ||
| LIGHT Luminous Flux | Warm White | 19500LM | |
| Pure White | 20500LM | ||
| Cool White | 21000LM | ||
| Viewing Angle: | 120/90/60 degree | ||
| Center Luminance | Height 6M | 228LUX | |
| Height 8M | 128LUX | ||
| Height 10M | 82LUX | ||
| Illuminance Area | Height 6M | Dia.929CM points visible | |
| Height 8M | Dia.1239CM points visible | ||
| Height 10M | Dia.1549 CM points visible | ||
| Illuminance Uniformity: | >0.6 | ||
| Color Temperature | Warm White | 3000K~3500K | |
| Pure White | 5000K~5700K | ||
| Cool White | 6000K~6500K | ||
| Color Rendering Index | Ra>80 | ||
| Light Distribution: | LED points visible | ||
| LED Junction Temperature: | ≤115℃ | ||
| Working Temperature: | –40℃~50℃ | ||
| IP Grade: | IP65 | ||
| Working Life-span: | 50000 H | ||
| Power Line: | 1.0 mm three line | ||
| Connect Wire | Brown | L | |
| Blue | N | ||
| Yellow / Green | G | ||
| Certificate | CE/ROHS | ||
| Size: | 328*H178.5 | ||
| Net Weight: | 4.5KG | ||
Warehouse UFO LED High bay Lamp Features:
1. UFO design LED High Bay light ,60W/100W/150W/200W all are avaliable ;
2. Samsung ,Lumileds ,OSRAM ,Epistar led chip all are available ;
3. The luminous efficacy of whole lamp can reach 135-160LM/W with high brightness ;
4. LED High bay light are adopted Metal plate pure aluminum heat sink and heat conduction by copper cylinder ;
5. Difference beam angle 60/90/120 degree distribution design as optional ;
6. Reflective rate >90%, CRI is more high,and Lighting is more comfortable ;
7. 304 Stainless steel,high quality, easy install,good rust prevention and durable ;
8. The welding spot highest temperature of LED Chip is 70ºC, the high temperature of heat sink is 55 ºC,with excellent heat dissipation capacity and low Light decay ,greatly improves the life of lamps ;
9. Installation ways :rings with chains or other installation accessories ;
10. Waterproof IP65 design ,widely use for indoor and outdoor ,suitable for warehouse ,industrial ,cold storage ,steel workshop etc .
UFO LED High Bay Competitive Advantage:
1. CE & RoHS & TUV&SAA approved, Quality Guaranteed
2. Imported original
SMD3030
chip, superior light source
3. OEM & ODM welcome, independent R&D ability, patent design.
4. Fast delivery, 2-15 workdays depends on order quantity after payment confirmed
5. Reliable quality & credit, 5 years warranty and 50.000 hours lifespan
Warehouse UFO LED High bay light structure :
Professional Dialux simulation of LED High bay light:
UFO LED High bay light Application:
1. Workshop and factory lighting.
2. Museum, stadium and gymnasium ,supermarket lighting.
3. Highway toll station and gas station lighting.
3. Warehouse and smeltery lighting.
UFO LED High bay light over 24hours aging test :
All LED lights will be over 24hours aging tested, inspection department will test 100% products ,including light up test , power wattage test ,highVoltage test , waterproof test , ground connection test and so on,defective rate is controlled less than 0.1%. Quality is ensured.
CE/RoHS/SAA Certification:
We has a group of professional technical R & D team, who can provide the OEM / ODM services according to customers and LED lighting solutions,our factory has passed the authentications of ISO9001:2000,CE, FCC, ROSH ,TUV authentication.
As a big led manufacturer with years of experiences,we Rayborn led lghting would very like to be your reliable lighting specialist. We ensure that:
1.Offering you the lowest price with good quality led lights.
2.Delivery the goods to you with speed and precision wherever you are.
3.Reply your inquiry and request in 8 hours during workdays.
4.Keep on researching and developing news prodcuts to satisfy your various needs.
5. Payment: T/T, L/C at sight, Western Union ,Paypal available
6. Samples can be available within 5-7 working days; Order: 10-20Days
7. Shipping freight is quoted under your requests
8. Shipping port:Shenzhen , China
9. Discounts are offered based on order quantities
