Quick Details
-
Insulation Material:
-
bare
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hopebond
-
Model Number:
-
resistance heating wire, FeCrAl alloy wire,OCr25Al5, OCr21Al4, OCr23Al5, OCr13Al9, OCr21Al6
-
size:
-
0.08-12mm
-
highest temperature:
-
1500 degree
-
Surface requirement:
-
Anealed soft,bright finish
-
Elongation %:
-
>14
-
Hardness:
-
200-260
-
Tensile strength:
-
637-784
-
Density:
-
7.35 g/cm3
Quick Details
-
Application:
-
Heating
-
Conductor Material:
-
Aluminum Clad Steel
-
Conductor Type:
-
Solid
-
Insulation Material:
-
bare
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hopebond
-
Model Number:
-
resistance heating wire, FeCrAl alloy wire,OCr25Al5, OCr21Al4, OCr23Al5, OCr13Al9, OCr21Al6
-
size:
-
0.08-12mm
-
highest temperature:
-
1500 degree
-
Surface requirement:
-
Anealed soft,bright finish
-
Elongation %:
-
>14
-
Hardness:
-
200-260
-
Tensile strength:
-
637-784
-
Density:
-
7.35 g/cm3
factory price resistance winding Cr20Ni80 spiral coil heating wire for heating element
Detail Description:
R esistance alloy wire is used for electrical heating element. Xingtai produced high-resistance electrothermal alloy products for the high-purity, low impurity resistivity stability, temperature coefficient small, superficial body Sexual good, and the higher intensity and high temperature performance and good processing may welding nature steels varieties specifications complete. Widely used in metallurgy, industrial stoves, household appliances, machinery and electronics manufacturing industries do heat resistance material.
1. FeCrAl Electrical Resistance Heating alloys with high electrical resistivity, temperature coefficient of resistance is small, high operating temperature. good corrosion resistance under high temperature, and particularly suitable for use in a gas containing sulfur and sulfides, low price, it is widely used in industrial electric furnace, household appliances, far infrared device ideal heating material.
FeCrAl type:1Cr13AI4, 0Cr21AI4, 0Cr21AI6, 0Cr25AI5, 0Cr21AI6 Nb, 0Cr27AI7Mo2 etc.Series electric flat belt, electric fire wire
2. Nickel chromium alloy with iron resistance electrothermal high resistivity, surface body sexual well. At high temperature and high intensity, and a good performance and processing may welding nature widely used metallurgical, electrical, mechanical components and electrical manufacturing industries for doing heat resistance material. Ni-Cr Type:Cr20Ni80,Cr15Ni60, Cr20Ni35, Cr20Ni30, Cr25Ni20 etc.Series electric flat belt, electric fire wire.
Product size:
wire dia.0.05—12mm; flat strip thickness 0.03—5mm,flat strip width0.2—500mm.
Main property :
| Material | OCr20Ni80 |
| Ni composition % | ≥77.5 |
| Max temperature | 1100 |
| Resistance RateμΩ·m(20°C) | 1.07-1.09±0.07 |
| Densityg/cm3 | 7.10 |
| Extensibility % | ≥20 |
| Material | OCr25Al5 |
| Cr composition % | 23.0-26.0 |
| Max temperature | 1250 c |
| Resistance RateμΩ·m(20°C) | 1.42±0.07 |
| Densityg/cm3 | 7.10 |
| Life celerity °C/h | ≥80/1300 |
Production photos:
Package:
Certification:
