Quick Details
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JZD
-
Model Number:
-
BVVB
-
Material:
-
100% Copper
-
Insulation:
-
PVC
-
Rated Voltage:
-
450 / 750 V
-
Jacket:
-
PVC
-
Standards:
-
National AS/NZS 1125; AS/ NZS 5000.2
-
Color:
-
With Green/Yellow core
-
Outer:
-
PVC
-
Sheath:
-
V-90
-
Number of earth cores:
-
1
-
Core:
-
3 Core
Quick Details
-
Application:
-
Other
-
Conductor Material:
-
Copper
-
Conductor Type:
-
Stranded
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JZD
-
Model Number:
-
BVVB
-
Material:
-
100% Copper
-
Insulation:
-
PVC
-
Rated Voltage:
-
450 / 750 V
-
Jacket:
-
PVC
-
Standards:
-
National AS/NZS 1125; AS/ NZS 5000.2
-
Color:
-
With Green/Yellow core
-
Outer:
-
PVC
-
Sheath:
-
V-90
-
Number of earth cores:
-
1
-
Core:
-
3 Core
Products Description
* Product standard:
The production standard for National AS/NZS 1125; AS/ NZS 5000.2
* Main of Cables Features:
1, Color: With Green/Yellow core
* Application:
Applicable to the cables and wires of rated voltage 450/750V and less than 450/750V AC for power plant, household electrical appliance, instrument, and telecommunication equipment.
The production standard for National AS/NZS 1125; AS/ NZS 5000.2
* Main of Cables Features:
1, Color: With Green/Yellow core
2,
Outer :PVC
3,
Sheath :V-90
4,
Number of earth cores:1
5,
Rated Voltage Uo/U (Um): 450/750V
6, Long-term allowable temperature of the cable:The allowable temperature of 105 Cable should not exceed 105℃, the allowable temperature of other models should not exceed 70℃.
* Application:
Applicable to the cables and wires of rated voltage 450/750V and less than 450/750V AC for power plant, household electrical appliance, instrument, and telecommunication equipment.
*
Certification
:
CE/CCC/SAA
The quality is guaranteed, and you do not need to worry about the problem of Import clearance in AU.
|
Cross
section [mm2]
|
Type of conductor
|
Number and diameter of
wires No/mm |
Nom. insulation
thick. [mm] |
Nom. outer sheath thick. [mm]
|
Earth cond.
sect. [mm2] |
Nom. over, diam.
|
Approx, weight [kg/100m]
|
Nexans ref.
|
|
1
|
Solid copper
|
1/1.13
|
0.6
|
0.9
|
1
|
8.9 x 4.2
|
7.74
|
2*1mm² +1 E
|
|
1
|
Solid copper
|
1/1.13
|
0.6
|
0.9
|
1
|
8.9 x 4.2
|
7.74
|
2*1mm² +1 E
|
|
1
|
Solid copper
|
1/1.13
|
0.6
|
0.9
|
1
|
8.9 x 4.2
|
7.74
|
2*1.5mm² +1.5 E
|
|
1.5
|
Stranded copper
|
7/0.52
|
0.6
|
0.9
|
1.5
|
9.9 x 4.5
|
8.86
|
2*1.5mm² +1.5 E
|
|
1.5
|
Stranded copper
|
7/0.52
|
0.6
|
0.9
|
1.5
|
9.9 x 4.5
|
13.29
|
2*1.5mm² +1.5 E
|
|
1.5
|
Stranded copper
|
7/0.52
|
0.6
|
0.9
|
1.5
|
9.9 x 4.5
|
8.86
|
2*1.5mm² +1.5 E
|
|
1.5
|
Stranded copper
|
7/0.52
|
0.6
|
0.9
|
1.5
|
9.9 x 4.5
|
8.86
|
2*1.5mm² +1.5 E
|
|
1.5
|
Stranded copper
|
7/0.52
|
0.6
|
0.9
|
1.5
|
9.9 x 4.5
|
8.86
|
2*1.5mm² +1.5 E
|
|
2.5
|
Solid copper
|
1/1.77
|
0.7
|
1.0
|
2.5
|
11.8x5.4
|
13.68
|
2*2.5mm² +2.5 E
|
|
2.5
|
Stranded copper
|
7/0.67
|
0.7
|
1.0
|
2.5
|
12.2x5.4
|
14.03
|
2*2.5mm² +2.5 E
|
|
2.5
|
Stranded copper
|
7/0.67
|
0.7
|
1.0
|
2.5
|
12.2x5.4
|
14.03
|
2*2.5mm² +2.5 E
|
|
2.5
|
Stranded copper
|
7/0.67
|
0.7
|
1.0
|
2.5
|
12.2x5.4
|
14.03
|
2*2.5mm² +2.5 E
|
|
2.5
|
Stranded copper
|
7/0.67
|
0.7
|
1.0
|
2.5
|
12.2x5.4
|
14.03
|
2*2.5mm² +2.5 E
|
|
2.5
|
Stranded copper
|
7/0.67
|
0.7
|
1.0
|
2.5
|
12.2x5.4
|
14.03
|
2*2.5mm² +2.5 E
|
|
2.5
|
Stranded copper
|
7/0.67
|
0.7
|
1.0
|
2.5
|
12.2x5.4
|
14.03
|
2*2.5mm² +2.5 E
|
|
2.5
|
Stranded copper
|
7/0.67
|
0.7
|
1.0
|
2.5
|
12.2x5.4
|
14.03
|
2*2.5mm² +2.5 E
|
|
2.5
|
Stranded copper
|
7/0.67
|
0.7
|
1.0
|
2.5
|
12.2x5.4
|
14.03
|
2*2.5mm² +2.5 E
|
|
4
|
Stranded copper
|
7/0.85
|
0.8
|
1.1
|
2.5
|
13.9x6.3
|
18.65
|
2*4mm² +2.5 E
|
|
4
|
Stranded copper
|
7/0.85
|
0.8
|
1.1
|
2.5
|
13.9x6.3
|
18.65
|
2*4mm² +2.5 E
|
|
4
|
Stranded copper
|
7/0.85
|
0.8
|
1.1
|
2.5
|
13.9x6.3
|
18.65
|
2*4mm² +2.5 E
|
|
4
|
Stranded copper
|
7/0.85
|
0.8
|
1.1
|
2.5
|
13.9x6.3
|
18.65
|
2*4mm² +2.5 E
|
|
4
|
Stranded copper
|
7/0.85
|
0.8
|
1.1
|
2.5
|
13.9x6.3
|
18.65
|
2*4mm² +2.5 E
|
|
4
|
Stranded copper
|
7/0.85
|
0.8
|
1.1
|
2.5
|
13.9x6.3
|
18.65
|
2*4mm² +2.5 E
|
|
6
|
Stranded copper
|
7/1.03
|
0.8
|
1.1
|
2.5
|
15.0x6.9
|
23.04
|
2*6mm² +2.5 E
|
|
6
|
Stranded copper
|
7/1.03
|
0.8
|
1.1
|
2.5
|
15.0x6.9
|
23.04
|
2*6mm² +2.5 E
|
|
6
|
Stranded copper
|
7/1.03
|
0.8
|
1.1
|
2.5
|
15.0x6.9
|
23.04
|
2*6mm² +2.5 E
|
|
6
|
Stranded copper
|
7/1.03
|
0.8
|
1.1
|
2.5
|
15.0x6.9
|
23.04
|
2*6mm² +2.5 E
|
