Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FLD
-
Dimension(L*W*H):
-
200x200x0.3mm
-
Weight:
-
200g
-
Warranty:
-
1
-
Certification:
-
CE&ROHS
-
Max.Usage tempature is 180℃:
-
Usage life more than 3 years
Quick Details
-
Type:
-
flexible kapton heater
-
Power Source:
-
Electric
-
Voltage:
-
12
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FLD
-
Dimension(L*W*H):
-
200x200x0.3mm
-
Weight:
-
200g
-
Warranty:
-
1
-
Certification:
-
CE&ROHS
-
Max.Usage tempature is 180℃:
-
Usage life more than 3 years
Customize 12V,24V,36V 3D printer flexible Kapton heater with CE certification,and we usually say it is polyimide heaters. This is is very thin,the thickness is about 0.3mm,it is very light,so it is widely used on 3D printer. the normal size for 3D printer are follow,
1,200x200mm,12v,200w
2,260x290mm,12v,145w
3,200x250mm,12v,90w
4,205x250mm,12v,96w
5, 200x240mm,12v,192w
6, 130x130mm,24v,120w
7, 158x178mm,24v,140w
8, 158x218mm,24v,200w
9, 200x240mm,24v,192w
10,205x205mm,24v,205w
11, 290x290mm,24v,300w
12, 300x300mm,24v,400w
and so on. any size,any shape can be customize. please contact with us.
NOTE: w e can custom according to your voltage, size, power and so on.
Some features are follow.
|
NO. |
Description |
Parameter |
|
1. |
Certification |
CE and Rohs |
|
2. |
Voltage range |
1.5v~400v |
|
3. |
Power density range |
0.03w/cm2~2.5w/cm2(0.19w/inch2~16.13w/inch2) |
|
4. |
Using temperature range |
-60~200°C(-140~392°F) |
|
5. |
Width range |
10mm~500mm(0.39"~19.68") |
|
6. |
Length range |
10mm~1800mm(0.39"~70.86") |
|
7. |
Thickness range |
Standard:0.126~0.266mm(0.005"~0.01") |
|
8. |
Plug |
Chinese,British, American, European and so on |
|
9. |
Quality guarantee |
1 year |
|
10. |
Life |
more than 4 years(normal useful) |
|
11. |
MOQ |
1 piece |
|
OEM and ODM is welcome,can print your logo |
||
If you have any other questions,please feel free contact us and welcome to our factory.
Main applications:
1
) Prevent condensation in motors or instrument cabinets;
2
) Freeze or condensation prevention in housings containing electronic equipment, for examples: traffic signal boxes, automatic teller machines, temperature control panels, gas or liquid control valve housings
3
) Composite bonding processes
4
) Semiconductor process heating
5
) Food processing equipment
6
) Airplane engine heaters and aerospace industry
7
) Drums and other vessels and viscosity control and asphalt storage
8
) Curing of plastic laminates
9
) Computer peripherals such as laser printers, duplicating machines
