Quick Details
-
electrical machinery:
-
72v4000w
-
Motor:
-
KDS
-
Warranty:
-
3years
-
OEM:
-
Acceptable
-
Color:
-
Customizable
-
Suspension:
-
MacPherson Independent Suspension System
-
Use:
-
Golf Cart Buggy Car
-
Type:
-
Electric Classic Golf Cart
-
Description:
-
4 People Electric Golf Car
-
Material:
-
Metal
Quick Details
-
Tire Size:
-
16inch
-
Dimension:
-
3350*1400*1880
-
Battery Voltage:
-
72V
-
electrical machinery:
-
72v4000w
-
Motor:
-
KDS
-
Warranty:
-
3years
-
OEM:
-
Acceptable
-
Color:
-
Customizable
-
Suspension:
-
MacPherson Independent Suspension System
-
Use:
-
Golf Cart Buggy Car
-
Type:
-
Electric Classic Golf Cart
-
Description:
-
4 People Electric Golf Car
-
Material:
-
Metal
Product Paramenters
|
Technical Parameter
|
|
|
|
curb weight
|
750KG
|
|
|
load
|
950KG
|
|
|
External dimensions
|
3350*1400*1880mm
|
|
|
bearing
|
2230mm
|
|
|
Front wheelbase
|
1250mm
|
|
|
Rear wheelbase
|
1230mm
|
|
|
Minimum ground clearance
|
150mm
|
|
|
Turning radius
|
5m
|
|
|
Maximum speed
|
(km/h)27
|
|
|
Climbing ability
|
(%)≥17
|
|
|
Range
|
100km
|
|
|
braking distance
|
(m)≤4
|
|
|
system configuration
|
|
|
|
electrical machinery
|
72v4000w
|
|
|
battery
|
72v150AH*9
|
|
|
accelerator
|
Resistance type, 0-5KDC
|
|
|
controller
|
72v/30A
|
|
|
charger
|
Intel Intelligent Controller
|
|
|
converter
|
INBOR DC12V/30A
|
|
|
Transmission mode
|
Mechatronics integrated
|
|
|
Front axle
|
MacPherson independent suspension
|
|
|
service brake
|
Four wheel hydraulic braking, vacuum assisted
|
|
|
Transmission:
|
nothing
|
|
|
Rear axle
|
Semi floating
|
|
|
Parking brake
|
Mechanical hand parking
|
|
|
Front suspension
|
MacPherson independent suspension
|
|
|
Rear suspension system
|
Plate+damper
|
|
|
tyre
|
165/70R12
|
|
|
Wheel hub
|
Aluminum alloy wheels
|
|
|
Steering gear
|
Circular ball style, without assistance
|
|
|
steering wheel
|
PU foam, covered with imitation leather
|
|
|
Car lights
|
Standard configuration
|
|
|
instrument
|
Metric system
|
|
|
body
|
Iron shell integrated stamping full load bearing body
|
|
|
Windshield glass
|
Tempered glass
|
|
|
Inner dimensions of the cargo box
|
1200 * 650 * 460mm (length, width, height)
|
|
|
Front and rear bumpers
|
Sheet metal split type
|
|
|
Front bumper size
|
1100 * 40 * 240mm (length, width, height)
|
|
|
Rear bumper size
|
1060 * 40 * 200mm (length, width, height)
|
|
|
rearview mirror
|
Standard configuration
|
|
|
Endoscope
|
Standard configuration
|
|
|
Audiovisual media
|
Standard configuration
|
|
|
seat
|
Imitation leather, flat sponge
|
|
|
Sun visor
|
Optional configuration
|
|
|
Reverse image
|
Standard configuration
|
|
|
Emergency stop switch
|
Standard configuration
|
|
|
allocation
|
Standard configuration
|
|
|
safety belt
|
Two point formula (optional)
|
|
|
sound
|
CD dual speaker ()
|
|
