Quick Details
-
Color:
-
full color
-
Panel Size:
-
500x500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-Bumblebee
-
Brightness:
-
800≤4500nits
-
pixel density:
-
65410dots/m2
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
1R1G1B
-
Lifespan (hours):
-
100000 hours
-
IP Rating:
-
IP31/IP65
-
Resolution:
-
128*256dots/cabinet
-
View Angle（H/V）:
-
160/160
-
Module size:
-
250x250 mm
-
Module Resolution:
-
64x64dots
-
Lamp type:
-
SMD1921
-
Scan mode:
-
1/16S
-
Cabinet material:
-
Die-casting Alumimum
-
Cabinet Weight:
-
7/13kg
-
Gray scale:
-
16bit
-
Refresh rate:
-
3840Hz
-
Installation:
-
Hanging and Standing Support
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
DDW
-
Color:
-
full color
-
Panel Size:
-
500x500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-Bumblebee
-
Brightness:
-
800≤4500nits
-
pixel density:
-
65410dots/m2
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
1R1G1B
-
Lifespan (hours):
-
100000 hours
-
IP Rating:
-
IP31/IP65
-
Resolution:
-
128*256dots/cabinet
-
View Angle（H/V）:
-
160/160
-
Module size:
-
250x250 mm
-
Module Resolution:
-
64x64dots
-
Lamp type:
-
SMD1921
-
Scan mode:
-
1/16S
-
Cabinet material:
-
Die-casting Alumimum
-
Cabinet Weight:
-
7/13kg
-
Gray scale:
-
16bit
-
Refresh rate:
-
3840Hz
-
Installation:
-
Hanging and Standing Support
标题
Discover Your Right Application , Make Your Business Possible !
Common warranty in LED field is 2 years, ours is 3 years Longer warranty
periods, better after-sale services, worry-free user experience
Products Description
Specifications
|
Item
|
P1.95
|
P2.6
|
P2.97
|
P3.91
|
P4.81
|
||||
|
Pixel Composition（SMD）
|
1415/1516
|
1415
|
1415
|
1921
|
2525
|
||||
|
Pixel Pitch（mm）
|
1.95
|
2.604
|
2.97
|
3.91
|
4.81
|
||||
|
Module Resolution（W×H）
|
128*128
|
96*96
|
84*84
|
64*64
|
52*52
|
||||
|
Module Size（mm）
|
250*250*15
|
250*250*15
|
250*250*15
|
250*250*15
|
250*250*15
|
||||
|
Module Weight（Kg）
|
0.58
|
0.58
|
0.58
|
0.58
|
0.58
|
||||
|
Module Qty/Cabinet
|
2*2
|
2*2
|
2*2
|
2*2
|
2*2
|
||||
|
Cabinet Size（mm）
|
500*500*87
|
500*500*87
|
500*500*87
|
500*500*87
|
500*500*87
|
||||
|
Cabinet Resolution（W×H）
|
256*256
|
192*192
|
168*168
|
128*128
|
104*104
|
||||
|
Cabinet Area（m²）
|
0.25
|
0.25
|
0.25
|
0.25
|
0.25
|
||||
|
Cabinet Weight（Kg）
|
7.5
|
7.5
|
7.5
|
7.5
|
7.5
|
||||
|
Cabinet Material
|
Die-cast aluminum
|
|
|
|
|
||||
|
Cabinet Density（dot/m²）
|
262144
|
147456
|
112896
|
65536
|
43264
|
||||
|
IP Rating
|
IP65
|
IP65
|
IP65
|
IP65
|
IP65
|
||||
|
Brightness（cd/m²）
|
4000≥600
|
4000≥600
|
4000≥600
|
4000≥600
|
4000≥600
|
||||
|
Color Temperature（K）
|
6500-9000
|
6500-9000
|
6500-9000
|
6500-9000
|
6500-9000
|
||||
|
Visual Angle（H/V）
|
140°/120°
|
140°/120°
|
140°/120°
|
140°/120°
|
140°/120°
|
||||
|
Contrast Ratio
|
5000:01:00
|
5000:01:00
|
5000:01:00
|
5000:01:00
|
5000:01:00
|
||||
|
The Max Power Consumption（W/m²）
|
700
|
700
|
700
|
700
|
700
|
||||
|
Average Power Consumption（W/m²）
|
235
|
235
|
235
|
235
|
235
|
||||
|
Input Voltage （V）
|
200-240
|
200-240
|
200-240
|
200-240
|
200-240
|
||||
|
Maintenance Method
|
Front and Rear
|
Front and Rear
|
Front and Rear
|
Front and Rear
|
Front and Rear
|
||||
|
Frequency
|
50&60
|
50&60
|
50&60
|
50&60
|
50&60
|
||||
|
IC Driving（Constant Current）
|
1/32s
|
1/24s
|
1/21s
|
1/16s
|
1/16s
|
||||
|
Grayscale
|
It is available within 65536
|
|
|
|
|
||||
|
Refreshing Ratio（Hz）
|
3840
|
3840
|
3840
|
3840
|
3840
|
||||
|
Color Processor
|
16bit
|
16bit
|
16bit
|
16bit
|
16bit
|
||||
|
Lifespan（h）
|
100000
|
100000
|
100000
|
100000
|
100000
|
||||
|
Work Temperature/Humidity
|
-10℃-50℃/10%RH-98%RH（no condensation）
|
|
|
|
|
||||
|
Storage Temperature/Humidity
|
-20℃-60℃/10%RH-98%RH（no condensation）
|
|
|
|
|
||||
