Quick Details
-
Place of Origin:
-
Shanghai, China
-
breed classify:
-
semi-killed steel OR killed steel
-
yield strength:
-
A36/235-260MPa S355JR/335-360MPa
-
Service:
-
A36/420MPa S355JR/485MPa
-
elongation:
-
A36/26min S355JR/26min
-
carbon content:
-
A36/C(0.12-0.20)% S355JR/C(0.12-0.20)%
-
manganese content:
-
A36/Mn(0.45)% S355JR/Mn(1.35)%
-
silicon content:
-
A36/Si(≥0.19)% S355JR/Si(≥0.002)%
-
phosphorus content:
-
A36/P(0.03)% S355JR/P(0.012)%
-
sulphur content:
-
A36/S(0.02)% S355JR/S(0.013)%
-
product name:
-
Steel plate
Quick Details
-
Type:
-
Steel Plate
-
Standard:
-
AiSi, ASTM, DIN, GB, JIS, EN
-
Grade:
-
S355JR,A36,SS400,ST37,ST52,
-
Place of Origin:
-
Shanghai, China
-
breed classify:
-
semi-killed steel OR killed steel
-
yield strength:
-
A36/235-260MPa S355JR/335-360MPa
-
Service:
-
A36/420MPa S355JR/485MPa
-
elongation:
-
A36/26min S355JR/26min
-
carbon content:
-
A36/C(0.12-0.20)% S355JR/C(0.12-0.20)%
-
manganese content:
-
A36/Mn(0.45)% S355JR/Mn(1.35)%
-
silicon content:
-
A36/Si(≥0.19)% S355JR/Si(≥0.002)%
-
phosphorus content:
-
A36/P(0.03)% S355JR/P(0.012)%
-
sulphur content:
-
A36/S(0.02)% S355JR/S(0.013)%
-
product name:
-
Steel plate
hot Rolled steel plate/bar/coil for boiler and pressure vessel steel,Q245R Q345R Q370R carbon steel sheet
| Hot Rolled Structural steel Mild Carbon Steel Plate | ||||
| Steel type | Carried standard | Steel grade | Level |
Thickness scope |
| Carbon Structural steel | GB/T 700-2006 | Q195 | - | 1.5~20 |
| Q215 | A,B | 1.5~20 | ||
| Q235 | A,B,C,D | 1.5~300 | ||
| Q275 | ||||
| EN 100025-2:2004 | S235 | JR,J0,J2,K2 | 1.5~300 | |
| S275 | 1.5~300 | |||
| S355 | 3.0~300 | |||
| ASTM A36/A36M-13 | A36 | - | 1.5~300 | |
| JIS 3101-2010 | SS330 | - | 1.5~300 | |
| SS400 | - | 1.5~300 | ||
| SS490 | - | 3.0~300 | ||
| SS540 | - | 3.0~300 | ||
| GB/T 710-2008 | 08,08Al,10,15, | - | 1.5~200 | |
| 20,30,35 | ||||
| GB/T 711-2008 | 08F,08,10F,20, | - | 1.5~120 | |
| 20Mn,60Mn | ||||
| ASTM A568/A568M-13 |
SAE1006, SAE1008 |
- | 1.5~300 | |
| Low alloy structural steel | ASTM A568/A568M-13 | Q345 | A,B,C,D,E | 3.0~300 |
| Q390 | A,B,C,D,E | 4.0~300 | ||
| Q420 | ||||
| Q460 | C,D,E | 6.0~300 | ||
| Q500 | ||||
| Q550 | ||||
| JIS G3106-2008 | SM400 | A,B,C | 1.5~300 | |
| SM490 | A,B,C | 3.0~300 | ||
| SM520 | B,C | 6~300 | ||
| SM570 | - | |||
| ASTM A572/A572M-13 | Gr42 | - | 1.5~300 | |
| Gr50 | - | 3.0~300 | ||
| Gr55 | - | 4.0~300 | ||
| Gr60 | - | 4.0~300 | ||
| Gr65 | - | 6.0~300 | ||
| Steel type |
Carried standard |
Steel grade |
Delivery Status |
Thickness scope |
|
Ship building structural steel plate |
ABS,BV,CCS, | A,B | AR | 6~40 |
| DNV, | ||||
| GL, KR,LR, | NR | 40~60 | ||
| NK RINA, | D | TMCP | 6~60 | |
|
RS Specifications of ten |
E | TMCP | 6~60 | |
| classification society | AH32 AH36 AH40 | TMCP | 6~60 | |
| DH32 DH36.DH40 | ||||
| EH32,EH36EH40 | ||||
| FH32 FH36.FH40 | ||||
Steel plate
