Chongqing Ogem Trade Co., Ltd has been specialized in service and supply of diesel engines and parts over 15 years, mainly focus on diesel engine models
NT855, KTA19, KTA38, KTA50, QSM11, 4BTA, 6BTA, 6CTA
etc. In April 2018, Ogem was launched to provide
better more service to global markets, with alternative quality parts for Generators, Mining& Truck, Marine Engines and Construction Equipments.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Chongqing, China
-
Dimension(L*W*H):
-
1679x872x1616mm
-
Weight:
-
2040
-
Rated power/speed:
-
2100RPM
-
Title:
-
KTA19 C600 for TEREX DUMP TRUCK TR60
-
Quality:
-
original
-
Application:
-
Machinery/Construction/Mining Truck
-
Product Name:
-
KTA19 c600
-
Packing:
-
Wooden case
-
Rated Power:
-
600/2100 HP/r/min
-
Maximum Torque:
-
2237/1500 N.m/r/min
-
After Warranty Service:
-
Video technical support
-
Delivery time:
-
25-30days
Quick Details
-
Displacement:
-
19 L
-
Emission Standard:
-
Euro 3
-
Power:
-
700HP
-
Place of Origin:
-
Chongqing, China
-
Dimension(L*W*H):
-
1679x872x1616mm
-
Weight:
-
2040
-
Rated power/speed:
-
2100RPM
-
Title:
-
KTA19 C600 for TEREX DUMP TRUCK TR60
-
Quality:
-
original
-
Application:
-
Machinery/Construction/Mining Truck
-
Product Name:
-
KTA19 c600
-
Packing:
-
Wooden case
-
Rated Power:
-
600/2100 HP/r/min
-
Maximum Torque:
-
2237/1500 N.m/r/min
-
After Warranty Service:
-
Video technical support
-
Delivery time:
-
25-30days
Product Description
Product Application
Constructions, Recreational Marine, Commercial Marine, Marine Auxiliary Engines, Marine Propulsion Engines.
|
Specifications For KTA19 C600 for TEREX dump truck TR60
|
|
|
|
|||
|
Engine Type
|
In-Line, 4-Cycle, 6-Cylinder
|
Quality
|
Original
|
|||
|
Rated Speed
|
2100 RPM
|
Oil System Capacity
|
80 U.S. qt(76 L*)
|
|||
|
Displacement
|
1,156 cu in(19 L*)
|
Coolant Capacity
|
44 U.S. qt(41.6 L*)
|
|||
|
Advertised Horsepower
|
450-700 hp(336-522 kW)
|
Length
|
66.1 in(1679 mm)
|
|||
|
Peak Torque
|
1125-2014 lb-ft
(1526-2731 N•m)
|
Width
|
34.3 in(872 mm)
|
|||
|
Bore and Stroke
|
6.25 in x 6.25 in
(159 mm x 159 mm)
|
Height
|
63.6 in(1616 mm)
|
|||
|
Aspiration
|
Turbocharged and Air-to-Air Charge Air Cooled
|
Weight (wet)
|
2000
kg
|
|||
|
Oil temperature(℃)
|
≤121
|
Compression Radio
|
15.9:1
|
|||
|
Constant load steady state volatility
|
±0.25%
|
Rated Power Production Tolerance
|
≦±5%
|
|||
Main Features
Standard Features.
PT Fuel System
– uses the time-tested and proven PT fuel system for high performance and ease of maintenance. PT injectors are built to handle high pressures for optimum combustion.
Fillet-Hardened Crankshaft
– smaller bolt circle and rolled threads for strength and durability
Cummins Prelub System
– Distributes and pressurizes oil in the engine before cranking can occur, and is proven to greatly extend life-to-rebuild.
Galley-cooled pistons
– reduced piston crown temperatures by as much as 100°F (38°C) for enhanced durability, reduced piston ring wear and 30% longer cylinder life.
Turbochargers
– Custom-built for K Series engines and are available in single-stage or two-stage configurations to meet any application's requirement.
We can offer these engine and spare parts as follow:
Features:
1. B3.3 /4B / 4BT /4C/4CT/ 6B / 6BT/ 6C / 6CT / 6L / ISBe /ISCe/ISDe/ISLe 2. K19 / K38 / K50 / NT855 3. ISM11/QSM11/QSX 15 4. ISF2.8/ISF3.8
5.Good quality&original
1. B3.3 /4B / 4BT /4C/4CT/ 6B / 6BT/ 6C / 6CT / 6L / ISBe /ISCe/ISDe/ISLe 2. K19 / K38 / K50 / NT855 3. ISM11/QSM11/QSX 15 4. ISF2.8/ISF3.8
5.Good quality&original
Main Engine Model
|
KTA19
|
KTAA19
|
KTTA19
|
QSk19
|
QSKTAA19
|
|
NT855
|
NTA855
|
NTAA855
|
KT38
|
KTA38
|
|
KT50
|
KTA50
|
KTTA50
|
M11
|
MTA11
|
|
MTAA11
|
4BT
|
6BT
|
6CT
|
ISF
|
diesel engine spare parts
Global Warranty Service
If you have demands for
ISF 4BT 6BT 6CT M11 NTA855 KTA19 KTA38 KTA50
diesel
engine and spare parts
,please click on the contact and we will provide you with the information you want to know in the most professional way!
Please feel free to contact!
>>>Click to Contact Us Now<<<
Related Products
|
K19 KTA19 QSK19 main parts list
|
|
|
|
|||
|
Part Name
|
|
Part Number
|
|
|||
|
Cylinder Head
|
|
3639984
|
|
|||
|
Cylinder Block
|
|
2896746
|
|
|||
|
Crankshaft
|
|
4910529
|
|
|||
|
Camshaft
|
|
3066882
|
|
|||
|
Cylinder Liner
|
|
4371769
|
|
|||
|
Piston
|
|
3096685
|
|
|||
|
Piston Ring
|
|
4089500
|
|
|||
|
Crankshaft Bearing
|
|
AR12270
|
|
|||
|
Connecting Rod Bearing
|
|
205840
|
|
|||
|
Fuel Injector
|
|
3003958
|
|
|||
|
Air Compressor
|
|
3052776
|
|
|||
|
Actuator
|
|
3103403
|
|
|||
|
Fuel Pump
|
|
4915474
|
|
|||
|
Water Pump
|
|
3098962
|
|
|||
|
Turbocharger
|
|
3594027
|
|
|||
|
ECM
|
|
3937299
|
|
|||
|
Cooling Core
|
|
206969
|
|
|||
|
Cylinder Gasket
|
|
3166289
|
|
|||
|
Alternator
|
|
3975140
|
|
|||
