Quick Details
-
Brand Name:
-
Sinta
-
Model Number:
-
STL-9015
-
Surface Treatment:
-
Grit ; pattern; concave ; flat
-
item name:
-
Fiberglass Plastic Floor Grid
-
other name:
-
Floor Grating with grit
-
Material:
-
fiberglass,frp,plastic
-
Grating thickness:
-
19,30,38,50mm and etc
-
grating panel size:
-
1220*3660mm, 1007*4047mm
-
Grating Color:
-
yellow, red, green, blue, white and etc
-
Resin:
-
high strength unsaturated polyester resin
-
surface treatment:
-
Grit ; pattern; concave ; flat
-
application:
-
floor, trench cover, protect tree
-
feature:
-
anti slip
Quick Details
-
Application:
-
protect tree and etc
-
Technique:
-
molded gratng from mould
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Sinta
-
Model Number:
-
STL-9015
-
Surface Treatment:
-
Grit ; pattern; concave ; flat
-
item name:
-
Fiberglass Plastic Floor Grid
-
other name:
-
Floor Grating with grit
-
Material:
-
fiberglass,frp,plastic
-
Grating thickness:
-
19,30,38,50mm and etc
-
grating panel size:
-
1220*3660mm, 1007*4047mm
-
Grating Color:
-
yellow, red, green, blue, white and etc
-
Resin:
-
high strength unsaturated polyester resin
-
surface treatment:
-
Grit ; pattern; concave ; flat
-
application:
-
floor, trench cover, protect tree
-
feature:
-
anti slip
Hebei SINTA FRP Product Co., Ltd is a professional fiberglass product manufacture in the north of China, mainly produce molded fiberglass products: grating, pultruded fiberglass profiles, such as rod, deformed bar, tube, plate, I-beam, corrugated panel, c channel and so on.
If you have fiberglass products demands, we sincerely welcome for your inquiry!
Product name: Fiberglass Plastic Floor Grid
Material: Resin(saturated Polyester Resin), Alkali free yarn
Surface Treatment: Grit ; Pattern ; concave ; flat
Color: Can choose color according to customer’s requirement, normal colors: yellow , grey, red, blue, green.
Fiberglass Plastic Floor Grid introduction>>
Fiberglass plastic floor grid is produced by glass fiber braiding, casting resin integral moulding, with many regular distribution of the rectangular and square space of glass fiber reinforced plastic grille plate, has two way mechanics characteristics. Can be widely used in oil, chemical electronics, electronic power, paper printing and dyeing, electroplating, marine exploration, sewage treament and other industries's work platfform, at the same time, can also be applied to civil construction facilities.
Fiberglass Plastic Floor Grid specification
>>
| fiberglass plastic floor grid Specification | ||||
| Thickness (mm) | Mesh size (mm) | Panel Size (mm) | Open Area % | Weight (kg/m 2 ) |
| 30 | 19 ×19/38 ×38 | 1220 × 3660 | 40 | 18.1 |
| 30 | 25 ×25/50 ×50 | 1000 × 4000 | 40 | 23.5 |
| 25 | 38 × 38 | 1220 × 3660 | 68 | 12.5 |
| 1007 × 4047 | ||||
| 30 | 38 × 38 | 1220 × 3660 | 68 | 14.75 |
| 1007 × 4047 | ||||
| 38 | 38 × 38 | 1220 × 3660 | 68 | 19.5 |
| 1007 × 4047 | ||||
| 50 | 50× 50 | 1220 × 3660 | 71 | 23.5 |
| 1007 × 4047 | ||||
| Rectangle Grid FRP Grating Specification | ||||
| Thickness (mm) | Mesh size (mm) | Panel Size (mm) | Open Area % | Weight (kg/m 2 ) |
| 25 | 25×100 | 3007×1009 | 67 | 13.8 |
| 30 |
25×100
|
3007×1009
|
67 | 15.6 |
| 38 | 152.4×38.1 | 3660×1220 | 72 | 17.8 |
| 38 |
25×100
|
3660×1220
|
62 | 22.5 |
| 38 | 38×100 |
3660×1220, 1220 ×2440 |
65 | 16.4 |
Fiberglass Plastic Floor Grid applications>>
- Flooring
- Bridges
- Ramps
- Walkways
- Platforms
- Assembly lines
- Wash bays
Fiberglass Plastic Floor Grid Benefits>>
- Anti slip surface
- Lightweight
- Fire Risistant
- Corrosion Resistant
- Non- Magnetic
- Impact Resistant
- Maintenance Free
- Attractive Design
| Packaging&Shipping | |
| Packaging | fiberglass plastic floor grid is wrapped by plastic film and plastic belt |
| Shipping | we would delivery cargo within 10 days after receivint the payment |
Good after-sale service attitude, help you resolve all the product problem.
Welcome your inquiry, want to know more info, welcome to contact me.
