Quick Details
Quick Details
-
Rated Power (HP):
-
40
-
Place of Origin:
-
China
-
Engine Brand:
-
top brand
|
Model |
1004 |
|
Drive type |
4x4 |
|
Engine |
|
|
Engine model |
LR4M3Z-23 |
|
Capacity of fuel tank(L) |
150 |
|
Rated speed (r/min) |
2300 |
|
Engine power (kw) |
69.9 |
|
Lowest fuel consumption (g/kw·h) |
≤242 |
|
Transmission |
|
|
Clutch |
Dry,Dual-stage type |
|
PTO Speed(rpm) |
540/1000 or 760/1000(optional) |
|
Gear shift |
16F+8R SHUTTLE SHIFT |
|
Hydraulic system |
|
|
Hydraulic output valve |
4-Way (optional) |
|
Three point linkage |
|
|
Category of 3-point link |
Category II |
|
Lifting capacity(at point
|
16 |
|
Technical parameter |
|
|
Dimension LxWxH mm |
4593x2050x2810 |
|
Wheel base(mm) |
2195 |
|
Track base(mm) front wheel |
1610 |
|
Track base(mm) rear wheel |
1620-2020 (usual 1620) |
|
The smallest clearance(mm) |
379 |
|
Front tyre |
12.4-24 |
|
Rear tyre |
16.9-34 |
