Quick Details
-
Warranty:
-
1 year
-
Certificate:
-
CE/FCC/Rohs/ISO9001
-
Type:
-
AHD HDD Mobile DVR
-
Resolution:
-
Support 1080P/720P/D1/CIF, MAX 8 channels 1080P
-
Video Compression:
-
H.265 Compression Mode
-
Video input:
-
8CH AHD1080P, aviation connector.
-
Video output:
-
2CH CVBS + VGA output for optional, 1.0Vp-p, 75Ω
-
Storage:
-
2.5'' HDD+ SD Card,each max 2TB HDD + 128GB SD Card
-
GPS 3G 4G Wifi:
-
Optional
-
Software:
-
CMSV6
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FL & OEM
-
Model Number:
-
FL-H10-04
-
Warranty:
-
1 year
-
Certificate:
-
CE/FCC/Rohs/ISO9001
-
Type:
-
AHD HDD Mobile DVR
-
Resolution:
-
Support 1080P/720P/D1/CIF, MAX 8 channels 1080P
-
Video Compression:
-
H.265 Compression Mode
-
Video input:
-
8CH AHD1080P, aviation connector.
-
Video output:
-
2CH CVBS + VGA output for optional, 1.0Vp-p, 75Ω
-
Storage:
-
2.5'' HDD+ SD Card,each max 2TB HDD + 128GB SD Card
-
GPS 3G 4G Wifi:
-
Optional
-
Software:
-
CMSV6
Details Images
Parameter
|
Item
|
Parameter
|
Description
|
|
System
|
Operational language
|
Chinese. English, Others (customizable)
|
|
|
Operation interface
|
Graphical menu operation interface (OSD menu)
|
|
|
Password security
|
Two-level management of user password and
administrator password |
|
Video
|
Video input
|
4/8 video input
|
|
|
Video output
|
There are two video output modes of VGA and aviation head interface
|
|
|
Video resolution
|
Support 1080P. 720P, D1, HD1, CIF, etc
|
|
|
Video loop recording
|
Support SD card automatic loop recording and loop overlay (auto default)
|
|
|
Video mode
|
Support boot recording, timing recording, alarm (trigger) recording
|
|
|
Image compression
|
H264/H265
|
|
Display
|
Preview features
|
Supports single and multi-view
|
|
|
OSD overlay display
|
Channel name, time, recording status, resolution, license plate, GPS information, etc
|
|
Alarm
|
IO alarm
|
4 IO alarm inputs, with alarm linkage function
|
|
Communication interface
|
RS232 interface
|
1CH RS232, expandable card machine, oil sensor, LED advertising screen, etc
|
|
|
RS485 interface
|
1-way 485 interface, expandable gimbal
|
|
AI capabilities
(Extensible) |
Passenger counting
|
1 door passenger counting
|
|
|
|
2 doors passenger counting
|
|
|
|
3 doors passenger counting
|
|
|
|
4 doors passenger counting
|
|
|
DMS
|
Fatigue (closed eyes, hatcher) detection alarm
|
|
|
|
Occlusion camera detection alarm
|
|
|
|
Receiving and receiving phone calls to detect alarms
|
|
|
|
Face loss detection alarm
|
|
|
|
Distraction detection alarm
|
|
|
|
Smoking detection alarm
|
|
|
ADAS
|
Occlusion camera detection alarm
|
|
|
|
Lane departure detection alarm
|
|
|
|
Pedestrian detection warning
|
|
|
|
Vehicle distance detection and warning
|
|
|
BSD
|
Left blind zone detection alarm
|
|
|
|
Right blind zone detection alarm
|
|
Platform
|
Remote monitoring
platform |
Real-time monitoring, monitoring intercom, playback, video, high-definition screenshots, GPS data, alarm data upload
|
|
Others
|
Power consumption
|
≤10W
|
|
|
Operating temperature
|
-20℃ to +70℃
|
|
|
Operating humidity
|
20% to 80%
|
|
|
Size
|
161 （D）* 159（W）* 63（H） mm
|
|
|
Net weight
|
1.119KG
|
|
|
Power input
|
DC +10V - +36V
|
Accessory
Installation
H10 8CH Work Diagram
This device support 4G WIFI GPS and function customization,support 1*2TBHDD+1* 256SD card， 4 CH/8 CH 1080P/720P, mostly service for bus,taxi and trunk . Support real-time monitoring and tracking.
For bus
The
orientation of cameras are optional according to your needs.
For others vehicles
Real-time
transmit
date to user
MDVR Function
Vehicle remote management on PC/Mobile
Users can remotely manage and view all vehicles through
the app in the mobile phone and windows .
GPS Tacking
Through the app , the vehicles locations can be recorded ,
the user can choose the date to review
and tracking
the location.
Support Vehicle Solution
Support extensible card reader, oil sensor, temperature and humidity sensor, LED advertising screen, etc.
Can provide security for the vehicle, real-time monitoring of vehicle data
Certificate
CE ISO001 RoHS FCC
