Quick Details
-
Dimension (L*W*H):
-
482.6*530*178mm
-
Weight:
-
About 39-45kg
-
Product Name:
-
51.2V 100Ah (LiFePO4) Battery
-
Cycle Life:
-
4000-6000+ Times
-
Application:
-
Home Energy Storage, RV, Tower Base Station,Solar Energy Storage
-
Warranty:
-
5years
-
Certification:
-
CE/IEC/RoHS/FCC/UN38.3/MSDS/IEC
-
OEM/ODM:
-
Accepatable
-
Type:
-
Li-Ion/lithium/lifepo4
-
BMS:
-
Built-in
-
MOQ:
-
1 Pcs
-
Battery cell:
-
A- Grade lifepo4 battery cell
Quick Details
-
Model Number:
-
YB-LF51100 48v 100Ah
-
Brand Name:
-
YABO
-
Place of Origin:
-
Guangdong, China
-
Dimension (L*W*H):
-
482.6*530*178mm
-
Weight:
-
About 39-45kg
-
Product Name:
-
51.2V 100Ah (LiFePO4) Battery
-
Cycle Life:
-
4000-6000+ Times
-
Application:
-
Home Energy Storage, RV, Tower Base Station,Solar Energy Storage
-
Warranty:
-
5years
-
Certification:
-
CE/IEC/RoHS/FCC/UN38.3/MSDS/IEC
-
OEM/ODM:
-
Accepatable
-
Type:
-
Li-Ion/lithium/lifepo4
-
BMS:
-
Built-in
-
MOQ:
-
1 Pcs
-
Battery cell:
-
A- Grade lifepo4 battery cell
Products Specification
|
Electrical Characteristics
|
Nominal Voltage
|
48V
|
|
|
Nominal Capacity
|
96Ah, 90Ah, 84Ah, 100Ah
@0.2C
|
|
|
Energy
|
4915Wh, 4608Wh, 4300Wh, 5120Wh
|
|
|
Internal Resistance
|
≤35mΩ
|
|
|
Cycle Life
|
4000-6000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity
|
|
|
Self Discharge
|
≤3.5% per month at 25℃
|
|
Standard Charging
|
Max.Charging Voltage
|
14.0~14.6V
|
|
|
Charging Mode
|
At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and then,changed continuously with constant voltage of
|
|
|
|
14.6V until the current was not more than 0.02C
|
|
|
Charging Current
|
100A
|
|
|
Max.Charging Current
|
100A
|
|
Standard Discharging
|
Discharging Current
|
100A
|
|
|
Max. Continuous Current
|
100A
|
|
|
Max.Pulse Current
|
110A(<10S）
|
|
|
Discharging Cut-off Voltage
|
40
|
|
Operating Condition
|
Charge Temperature
|
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
|
|
|
Discharge Temperature
|
-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
|
|
|
Storage Temperature
|
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
|
|
|
Water Dust Resistance
|
IP55
|
|
Structure
|
OEM ODM
|
YES
|
|
|
Casing
|
Mental
|
|
|
Dimension(L*W*H*TH)
|
482.6*530*178mm 4U
|
|
|
Weight
|
Approx.39-45Kg
|
|
|
Communication Interface
|
RS485A+RS485B
|
|
|
|
CAN or RS485
|
Details Images
Support Inverter
Packaging List and Shipping
Certifications
Contact Us
FAQ
Q1. Can I have a sample order?
A. Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A. Sample needs 7 days, mass production time needs 5-7 weeks, it depends on order quantity.
Q3. Do you have any MOQ limit?
A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-7 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed with an order?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7.Which certificates do you have?
A:We have CE/FCC/ROHS/UN38.3/MSDS/IEC/CB ...etc.
Q8.How about warranty?
A:5 year warranty.
