Quick Details
-
Application:
-
automotives
-
Line regulation:
-
±0.2%
-
Load regulation:
-
±0.2%
-
Voltage accuracy:
-
±1.5%
-
Temperature coefficient:
-
±0.03%/°C
-
Cooling:
-
free air convection
-
Enclosures:
-
IP68
-
Safety approvals:
-
ISO 7637-2:2004
-
Warranty:
-
1 year
Quick Details
-
Output Current:
-
8A
-
Place of Origin:
-
Guangdong, China
-
Categories:
-
12V 24V to 14.5V 8A DC TO DC Regulated Voltage Step Up-Down Charger
-
Application:
-
automotives
-
Line regulation:
-
±0.2%
-
Load regulation:
-
±0.2%
-
Voltage accuracy:
-
±1.5%
-
Temperature coefficient:
-
±0.03%/°C
-
Cooling:
-
free air convection
-
Enclosures:
-
IP68
-
Safety approvals:
-
ISO 7637-2:2004
-
Warranty:
-
1 year
12V/24V to 14.5V 8A DC/DC Converter Charger
Wide input voltage from 11-30V
Stable output voltage is 14.5V
100% full rated power
100% full stable output current
100% burn-in test
Typical efficiency is 95%
Waterproof sealed
Cooling by free air convection
Surface mountable
1 year warranty
Over-current, over-voltage protections
Over-temperature protections
According to: EN 50498:2010 IP68
This product is customized and can be consulted at any time
|
Daygreen P/N
|
A1T2C14R508
|
|
Efficiency
|
95%
|
|
Input Voltage
|
11V-30VDC
|
|
Output Voltage
|
14.5VDC
|
|
Output Current
|
8A
|
|
Ripple
|
100mVp
|
|
Line Regulation
|
±0.2%
|
|
Load Regulation
|
±0.2%
|
|
Voltage Accuracy
|
±1.5%
|
|
Enclosures
|
IP68
|
|
Dimension
|
5.9 x 5 x 2.48 inch
|
|
Net Weight
|
3.3 lb
|
|
Ambient temperature
|
-20~60°C
|
|
Operation temperature
|
-40~80°C
|
|
Warranty
|
1 year
|
