Quick Details
-
Model Number:
-
YSE90-4
-
Frequency:
-
1500r/min
-
color:
-
cutomizable
-
Current:
-
7.5A
-
Insulation class:
-
B/F/H
-
StallTorque:
-
16N.m
-
Braking torque:
-
2-10N.m
-
weight:
-
30kg
-
Material:
-
Aluminum
-
protection class:
-
IP44
-
Scope of application:
-
Speed reducer
Quick Details
-
AC Voltage:
-
220V/380V
-
Place of Origin:
-
China
-
Brand Name:
-
Anlian
-
Model Number:
-
YSE90-4
-
Frequency:
-
1500r/min
-
color:
-
cutomizable
-
Current:
-
7.5A
-
Insulation class:
-
B/F/H
-
StallTorque:
-
16N.m
-
Braking torque:
-
2-10N.m
-
weight:
-
30kg
-
Material:
-
Aluminum
-
protection class:
-
IP44
-
Scope of application:
-
Speed reducer
Product description
1.The gear box is made of high stress cast iron (FC25),and manufacture by computer numericl
central machinery(CNC LATHE& CNC machining center).
2.The shaft is manufacture by alignment and grinding. So the accuracy is very good. The stress is very strong. The safety factor is more than 5. The product-life is very long.
3. High performance of start torque, motor body is simple for radiation, high-pressure resisting more than "1500V, light current,Compact - sized, powerful output, available for high frequency.
technical parameter
|
type
|
power(kw)
|
torque(n.m)
|
current(A）
|
speed(r/min)
|
weight(kg)
|
|
YSE80-4
|
0.2
|
2
|
1.5
|
1200
|
12
|
|
YSE801-4
|
0.4
|
4
|
2.8
|
1200
|
15
|
|
YSE802-4
|
0.8
|
8
|
3.6
|
1200
|
18
|
|
YSE90S-4
|
1.1
|
12
|
6.2
|
1200
|
28
|
|
YSE90L-4
|
1.5
|
16
|
7.5
|
1200
|
30
|
|
YSE100L1-4
|
2.2
|
24
|
10
|
1200
|
42
|
|
YSE100L2-4
|
3.0
|
30
|
12
|
1200
|
45
|
|
YSE112M-4
|
4.0
|
40
|
17
|
1200
|
55
|
|
YSE132S-4
|
5.5
|
52
|
24
|
1200
|
80
|
|
YSE90S-6
|
0.5
|
8
|
4
|
800
|
18
|
|
YSE90L-6
|
0.8
|
12
|
5
|
800
|
28
|
|
YSE100L-6
|
1.5
|
23
|
8
|
800
|
42
|
|
YSE112M-6
|
2.2
|
33
|
11.5
|
800
|
51
|
|
YSE132S-6
|
3.0
|
46
|
16
|
800
|
81
|
|
YSE132M1-6
|
4.0
|
60
|
19
|
800
|
90
|
Our services
1. Product Model.
2. Motor Power.
3. Voltage.
4. Vibration Frequency.
About Delivery: Generally, 15 days after receiving your deposit and after the order confirmed.
About Payment: L/C, T/T or others you like.
FAQ
Q1: What is our factory product range?
A:We are specialize in crane, electric motors, wire rope hoists, electric winches and concrete vibrators, etc. for many years.
Q2:How about sample policy?
A:Welcome sample order. Please inform your detailed sample requirement, such as the quantity, the capacity, the chain, the lift and so on. If we have the sample in stock , the ship will be quicker. If we don’t have stock, please understand to wait for the produce. Express fee is charged by the shipping company. The sample fee and express fee usually paid by client, for special policy need to apply by client and approved by our leaders.
Q3: How to order?
A: Please send us your purchase order by Email or Fax, or you can ask us to send you Performa Invoice for your order. We need to know the following information for your order:
1)About product: Quantity, Specification (span, lifting height, material, color and packing requirement and so on).
2) Delivery time required.
3) Shipping information: Company name, Address, Phone number, Destination seaport/airport.
4) Forwarder's contact details if there is any in China.
Q4: What advantages we have?
A: 1) One to one service guarantees the best purchasing experience for you.
2) Strong production capacity and professional workmen guarantee you the short delivery.
Strict delivery inspection guarantees the high quality products.
