Quick Details
-
Brand Name:
-
Hirschmann
-
Product name:
-
Managed Compact OpenRail Fast Ethernet Switch
-
Ports:
-
8 Ports
-
Model:
-
RS20-0800M2M2SDAUHH/HC
-
Brand:
-
Hirschmann
-
Dimension:
-
74 mm x 131 mm x 111 mm
-
Warranty:
-
1 Year
-
Weight:
-
410g
-
Operating temperature:
-
0 -60
Quick Details
-
Type:
-
Enterprise Switch
-
Model Number:
-
RS20-0800M2M2SDAUHH/HC
-
Place of Origin:
-
Germany
-
Brand Name:
-
Hirschmann
-
Product name:
-
Managed Compact OpenRail Fast Ethernet Switch
-
Ports:
-
8 Ports
-
Model:
-
RS20-0800M2M2SDAUHH/HC
-
Brand:
-
Hirschmann
-
Dimension:
-
74 mm x 131 mm x 111 mm
-
Warranty:
-
1 Year
-
Weight:
-
410g
-
Operating temperature:
-
0 -60
Hirschmann Switch RS20-0800M2M2SDAU Managed Compact OpenRail Fast Ethernet Switch 8 Ports
8 port Fast-Ethernet-Switch, unmanaged, for DIN rail store-and-forward-switching, fanless design
Technical Specifications
|
Description |
8 port Fast-Ethernet-Switch, unmanaged, for DIN rail store-and-forward-switching, fanless design |
|
Part Number |
RS20-0800M2M2SDAU |
|
Port type and quantity |
8 ports in total; 1. uplink: 100BASE-FX, MM-SC; 2. uplink: 100BASE-FX, MM-SC; 6 x standard 10/100 BASE TX, RJ45 |
More Interfaces
|
Power supply /signaling contact |
1 x plug-in terminal block, 6-pin |
Network size - length of cable
|
Multimode fiber (MM) 50/125 µm |
0 - 5000 m, 8 dB link budget at 1300 nm, A = 1 d/km, 3 dB reserve, B = 800 MHz x km |
|
Multimode fiber (MM) 62.5/125 µm: |
0 - 4000 m, 11 dB link budget at 1300 nm, A = 1 dB/km, 3 dB reserve, B = 500 MHz x km |
Network size - cascadibility
|
Line - / star topology |
any |
Power requirements
|
Current consumption at 24 V DC: |
321 mA |
|
Current consumption at 48 V DC |
161 mA |
|
Operating voltage |
12/24/48 V DC (9,6-60) V and 24 V AC (18-30) V (redundant) |
|
Power output in Btu (IT) h |
26.3 |
Diagnostics features
|
Diagnostic functions: |
LEDs (power, link status, data, data rate) |
Ambient conditions
|
MTBF (MIL-HDBK 217F: Gb 25 ºC) |
53.5 years |
|
Operating temperature: |
0 ºC ... 60 ºC |
|
Storage/transport temperature: |
-40 ºC ... 70 ºC |
|
Relative humidity (non-condensing): |
10-95 % |
Mechanical construction
|
Dimensions (WxHxD): |
74 mm x 131 mm x 111 mm |
|
Weight: |
410 g |
|
Mounting: |
DIN Rail, |
|
Protection class: |
IP20 |
