- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Lvhua
-
Voltage:
-
Customized
-
Dimension(L*W*H):
-
2700*1000*1800
-
Power (kW):
-
15
-
Weight (T):
-
3
-
Model:
-
AT800
-
Motor:
-
2*7.5kw
-
Capacity:
-
100-1200kg/h
-
Blade:
-
40pcs
-
Blade length:
-
800mm
-
Rotate speed:
-
15r/min
-
Electric Control:
-
PLC Control
-
Shredding chamber:
-
513*810mm
-
Outside dimension:
-
2720*890*1850mm
-
Weight:
-
3000kg
Quick Details
-
Max.Production Capacity (kg/h):
-
1200
-
Place of Origin:
-
Zhejiang, China
-
Production Capacity (kg/h):
-
100 - 1200 kg/h
-
Brand Name:
-
Lvhua
-
Voltage:
-
Customized
-
Dimension(L*W*H):
-
2700*1000*1800
-
Power (kW):
-
15
-
Weight (T):
-
3
-
Model:
-
AT800
-
Motor:
-
2*7.5kw
-
Capacity:
-
100-1200kg/h
-
Blade:
-
40pcs
-
Blade length:
-
800mm
-
Rotate speed:
-
15r/min
-
Electric Control:
-
PLC Control
-
Shredding chamber:
-
513*810mm
-
Outside dimension:
-
2720*890*1850mm
-
Weight:
-
3000kg
Product Overview
MODEL:
AT800
Feature:
1.Slow speed, large torque, generally 3-15 RPM, almost no noise in the crushing process.
2.Broken through the meshing shear of the blade.
3.No screen, the broken material and blade width is consistent, the length is related to the diameter of the claw, the number of the claw, the length of the material can be controlled by making different claw number of blades.
4.Plastic, plate, wood, metal, can be broken, can achieve large output crushing.
2.Broken through the meshing shear of the blade.
3.No screen, the broken material and blade width is consistent, the length is related to the diameter of the claw, the number of the claw, the length of the material can be controlled by making different claw number of blades.
4.Plastic, plate, wood, metal, can be broken, can achieve large output crushing.
Advantages:
1.Small power, large torque, suitable for a large output crushing
2.Can crush a variety of materials, including metal
3.The tool has long service life and is not easy to wear.
2.Can crush a variety of materials, including metal
3.The tool has long service life and is not easy to wear.
Product Description
Machine Parameters
|
Model
|
Power
|
Blade Roller diameter
|
Rotate speed
|
Length
|
Width
|
High
|
|
AT400
|
7.5kw
|
Φ280mm
|
15r/min
|
1600mm
|
1845mm
|
1260mm
|
|
AT600
|
2*5.5kw
|
Φ280mm
|
15r/min
|
2500mm
|
1845mm
|
1275mm
|
|
AT800
|
2*7.5kw
|
Φ280mm
|
15r/min
|
2720mm
|
1845mm
|
1275mm
|
|
AT1200
|
2*22kw
|
Φ430mm
|
15r/min
|
3120mm
|
2217mm
|
1965mm
|
