Quick Details
-
Brand Name:
-
LNA
-
Place of Origin:
-
Hubei, China
-
Type:
-
Switchable 2WD/4WD
-
Battery:
-
72v/32a
-
Size:
-
2220*1200*1230mm
-
Wheels:
-
12" Alloy
-
Max weight load:
-
300-400 kg
-
Weight:
-
290 kg
-
Range per charge:
-
60-70 km
-
Top speed:
-
55-60 km/h
-
Drive:
-
Shaft
Quick Details
-
Power:
-
> 1000W
-
Tire Size:
-
25*8-12/25*10-12
-
Dimension:
-
2220*1200*1230mm
-
Brand Name:
-
LNA
-
Place of Origin:
-
Hubei, China
-
Type:
-
Switchable 2WD/4WD
-
Battery:
-
72v/32a
-
Size:
-
2220*1200*1230mm
-
Wheels:
-
12" Alloy
-
Max weight load:
-
300-400 kg
-
Weight:
-
290 kg
-
Range per charge:
-
60-70 km
-
Top speed:
-
55-60 km/h
-
Drive:
-
Shaft
Product Description
Specification
|
Model Number
|
LNA-EA5000
|
Power
|
5000W
|
|
Type
|
Switchable 2WD/4WD
|
Electric Motor
|
Dual Brushless Motor
|
|
Range
|
60-70 km
|
Top speed
|
55-60 km/h
|
|
Voltage
|
72v
|
Size
|
2220*1200*1230mm
|
|
Battery
|
32a
|
Drive
|
Shaft
|
|
Weight
|
290kg
|
Max weight load
|
300-400 kg
|
|
Speedmeter
|
LED
|
Wheel size
|
12" Alloy
|
|
Wheelbase
|
1310mm
|
Brake
|
Hydraulic Disc
|
|
Charging time
|
5-7 hours
|
Packing size
|
2330*1270*1060mm
|
|
Shaft type
|
Integrated
|
Ground clearance
|
240mm
|
|
Seat height
|
870mm
|
Front suspension travel
|
179mm
|
|
Rear suspension travel
|
203mm
|
|
|
Detailed Pictures
The Rider Seat
The huge rider-seat provides spacious space for the riders even you are tall and strong ,the knees and legs will be comfortable when ride.
Left Handle
The Right Handle
3 Speeds and Forward/Reverse Gears
LED Speedmeter
The smart LED speedmeter shows speed,miles,battery,all the info can be easily seeing
off road LED Light Bar
The huge LED light bar provides real good view even ride in the night.
Electric Motors and Battery
The battery and electric motors are fixed on the main frame of the ATV,not just attached on the chassis
it guarantees the body strength
Huge Seat for 2 Persons and Back Rest
Absolutely huge enough for 2 adults ride
Front Luggage Area
Rear Luggage Area
4x4 in Front
A strong and reliable 4x4 system provides fantastic off road capacities, it helps when you need to make a haul or ride in the woods or mud.
Shaft Drive in Front
Shaft drive in front with Hydraulic Disc Brake
Integrated Rear Axle
the Integrated rear axle has much better rigidity performance when it is in off road ride.
the brake is important,so we provided 2
Hydraulic Disc Brakes in the rear
The Tow Bar Supported
Actual Pictures
Climbing Mountains
The 5000w power and 4x4 system provides confidence when ride in off road,it allows you ride in the mountains,on the mud,on the sands,in the jungles
Certifications
Product packaging
The packing is made by steel frame with carbon box and covered by plastic. strong enough for the transport.
