1. CE/EPA/GOST certificate
2. One-year Warranty
3. Wide-view Mast
4. Solid Overhead Guard
5. Ergonomics Seat
6. Powerful Engine
7. Non-slip step
8. With various humanization design...
- Product Details
- {{item.text}}
Quick Details
-
Fork Length:
-
1220mm
-
Fork Width:
-
150mm
-
Overall Dimensions:
-
3490 * 2045 * 2500mm
-
Weight (KG):
-
8500 kg
-
Product Name:
-
5ton to 7ton LPG forklift
-
Engine:
-
Kubota engine/ EPA engine
-
Forklift Mast:
-
Duplex/Duplex FFL/Triplex FFL
-
Lift heights:
-
3m to 6m
-
Transmission:
-
Hydraulic Gearbox Automatic Forklift
-
Forklift Tire:
-
Pneumatic/Solid
-
Gas tank quantity:
-
two
-
Color:
-
Yellow/Red/Blue/White
-
Forks length:
-
1220mm/1520mm
-
Forks sideshift:
-
optional
Quick Details
-
Min. Lifting Height:
-
200mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Zhejiang, China
-
Fork Length:
-
1220mm
-
Fork Width:
-
150mm
-
Overall Dimensions:
-
3490 * 2045 * 2500mm
-
Weight (KG):
-
8500 kg
-
Product Name:
-
5ton to 7ton LPG forklift
-
Engine:
-
Kubota engine/ EPA engine
-
Forklift Mast:
-
Duplex/Duplex FFL/Triplex FFL
-
Lift heights:
-
3m to 6m
-
Transmission:
-
Hydraulic Gearbox Automatic Forklift
-
Forklift Tire:
-
Pneumatic/Solid
-
Gas tank quantity:
-
two
-
Color:
-
Yellow/Red/Blue/White
-
Forks length:
-
1220mm/1520mm
-
Forks sideshift:
-
optional
Products Description
5ton 6ton 7ton LPG Forklift
|
General
|
1
|
Model
|
|
CPQYD50
|
|
|
2
|
Power Type
|
|
LPG/Gasoline
|
|
|
3
|
Rated Capacity
|
kg
|
5000
|
|
|
4
|
Load Centre
|
mm
|
600
|
|
Characteristic
& Dimension
|
5
|
Lift Height
|
mm
|
3000
|
|
|
6
|
Fork Size (L×W×T)
|
mm
|
1220×150×70
|
|
|
7
|
Mast Tilt Angle (F/R)
|
Deg
|
6°/12°
|
|
|
8
|
Front Overhang (Wheel center to fork face)
|
mm
|
595
|
|
|
9
|
Ground Clearance（Bottom of mast）
|
mm
|
200
|
|
|
10
|
Length to face of fork(Without fork)
|
mm
|
3490
|
|
|
11
|
Overall Width
|
mm
|
2045
|
|
|
12
|
Mast Lowered Height
|
mm
|
2500
|
|
|
13
|
Mast Extended Height(With backrest)
|
mm
|
4415
|
|
|
14
|
Overhead Guard Height
|
mm
|
2470
|
|
|
15
|
Turning Radius (outside)
|
mm
|
3350
|
|
Performance
|
16
|
Travel Speed (No load)
|
km/h
|
26
|
|
|
17
|
Lifting Speed (Full load)
|
mm/s
|
460
|
|
|
18
|
Max.Gradeability (No load/Full load)
|
%
|
20
|
|
Chassis
|
19
|
Front Tire
|
mm
|
8.25-15-14PR
|
|
|
20
|
Rear Tire
|
mm
|
8.25-15-14PR
|
|
|
21
|
Wheelbase
|
mm
|
2250
|
|
|
22
|
Self weight
|
kg
|
8200
|
|
Power &
Transmission
|
23
|
Battery Voltage/Capacity
|
V/Ah
|
(12V/80Ah) x 2
|
|
|
24
|
Engine Model
|
|
Kubota engine
|
|
|
32
|
Transmission Type
|
|
Hydraulic
|
|
|
33
|
Stage (FWD/RVS)
|
|
2/2
|
Our factory
Production line
Export to all over the world
Testing
