Quick Details
-
Tube Length(ft):
-
2, 3, 4, 8
-
Input Voltage(V):
-
AC100-260V
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 60
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZEESTARLED
-
Model Number:
-
ZS-TL102-T840W
-
Product Name:
-
4ft T8 Led Tube Light Shop Lighting For Garage Warehouse Workshop
-
LED Chip:
-
SMD 2835
-
Length Optional:
-
0.3m/0.6m/0.9m/1.2m/1.5m/1.8m/2.4m
-
Power factor:
-
>0.9
-
CCT:
-
3000-3500K,4000-4500K,6000-6500K
-
Driver:
-
Isolated or non-isolated internal Driver
-
Irritation angle:
-
270
-
Cover:
-
Nano or full plastic or PC+AL or glass
-
Certification:
-
ce RoHS
Quick Details
-
Warranty(Years):
-
3
-
Lamp Luminous Efficiency(lm/w):
-
100
-
Lamp Body Material:
-
Aluminum + PC
-
Tube Length(ft):
-
2, 3, 4, 8
-
Input Voltage(V):
-
AC100-260V
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 60
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZEESTARLED
-
Model Number:
-
ZS-TL102-T840W
-
Product Name:
-
4ft T8 Led Tube Light Shop Lighting For Garage Warehouse Workshop
-
LED Chip:
-
SMD 2835
-
Length Optional:
-
0.3m/0.6m/0.9m/1.2m/1.5m/1.8m/2.4m
-
Power factor:
-
>0.9
-
CCT:
-
3000-3500K,4000-4500K,6000-6500K
-
Driver:
-
Isolated or non-isolated internal Driver
-
Irritation angle:
-
270
-
Cover:
-
Nano or full plastic or PC+AL or glass
-
Certification:
-
ce RoHS
|
Specification
|
|
|
|
Product Name
|
4ft T8 Led Tube Light Shop Lighting For Garage Warehouse Workshop
|
|
|
Power
|
5W/9W/12W/18W/22W/36W/48W/60W72W
|
|
|
Voltage
|
AC110-277V 50/60HZ
|
|
|
CCT
|
3000K/4000K/6000K
|
|
|
Integrated
|
Yes/No
|
|
|
Sensor
|
Yes/No
|
|
|
Waterproof
|
Yes/No
|
|
|
Length
|
0.6m/0.9m/1.2m/1.5m/1.8m/2.4m
|
|
Product Description
Advantages:
1. Big lighting angle 120°, high power factor(>0.9), low power but high lumen efficiency 140lm/w.
2. Isolated driver, more cheaper,over current protection. Eco-friendly, no mercury and harmful materials surely.
3. Anti-electric wave, no RF interference, and constant current driver.
4. Good function of heat dissipation, improving the lamp's lifetime and energy saving up to 60-80%.
5. Wide Application: Commercial building, factory, production line, warehouse, pathway lighting, street lighting, subway station etc.
6. Supply the products with different size and shape according to your requirements.
|
Model
|
Size(mm)
|
Power
|
Voltage
|
PF
|
CRI
|
Color Temperature
|
LED Qty
|
|
YH-T806A
|
L588
|
9W
|
AC85V-265V
|
>0.5
|
RA>80
|
2700k-6500k
|
60PCS
|
|
YH-T812A
|
L1198
|
18W
|
|
>0.5
|
RA>80
|
2700k-6500k
|
96PCS
|
|
YH-T815A
|
L1498
|
22W
|
|
>0.5
|
RA>80
|
2700k-6500k
|
120PCS
|
|
|
|
|
|
|
|
|
|
|
YH-T806B
|
L588
|
9W
|
AC85V-265V
|
>0.9
|
RA>80
|
2700k-6500k
|
60PCS
|
|
YH-T812B
|
L1198
|
18W
|
|
>0.9
|
RA>80
|
2700k-6500k
|
120PCS
|
|
YH-T815B
|
L1498
|
22W
|
|
>0.9
|
RA>80
|
2700k-6500k
|
144PCS
|
Benefits
.
Mercury-free , no hazardous waste disposal
.
Suitable for operation at low temperatures
.
Energy saving of up to 65% compared to t8 fluorescent lamp
Product Application
Factory, shopping malls, schools, warehouses, corridors, hotels, offices, showrooms etc.
Workshop photos
