Quick Details
-
Model Number:
-
GM-Mini
-
Brand Name:
-
DONJOY
-
Certificate:
-
3A, CE
-
Weight:
-
Depend on the final package
Quick Details
-
Port Size:
-
1/4"-3/4", DN6-DN15
-
Warranty:
-
1 year
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
GM-Mini
-
Brand Name:
-
DONJOY
-
Certificate:
-
3A, CE
-
Weight:
-
Depend on the final package
|
Availably size |
1/4"-3/4", DN6-DN15 |
|
Max. temperature |
-30 to 150 °C(depending on diaphragm) (stainless steel wheel) |
|
Max. temperature |
-30 to 130 °C (depending on diaphragm) (plastic wheel) |
|
Max. pressure |
Normally close EPDM 8 bar,PTFE 6 bar(option)
|
|
Actuators |
Assemble different actuators can meet the higher pressure rating |
|
Pneumatic actuators suitable for body |
straight,tee,multichannel body, welding combination valve, tank bottom valve |
|
Valve body |
316L / BPE 316L |
|
Availably connection |
Clamp / weld / thread / flange |
|
Seal Material |
PTFE + EPDM (double layer) / EPDM / SILICON / FPM (VITON) |
|
Availably standard |
3A/BPE/DIN/ISO/IDF |
|
Control |
Smart valve positioner / C-TOP control / position sensor |
|
Operated |
Manual,Pneumatic |
|
Certificate |
3A/54-02 (1580), PED/97/23/EC |
