Quick Details
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Curtain Side Semi Trailer
-
Wheelbase:
-
7450*1310*1310mm
-
Tare Weight:
-
7000 Kg
-
Axle Brand:
-
FuWa,BPW,SAF Brand
-
Suspension:
-
Common Mechanical Suspension/Air Suspension
-
Steel Spring:
-
10/10/10 leaf spring suspension
-
Side Beam:
-
18mm
-
OEM/ODM:
-
Available
-
Color:
-
Custom's Requirement
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
40000KG
-
Size:
-
13900*2500*4000mm(customized), Accroding Customer's Requirement
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Curtain Side Semi Trailer
-
Wheelbase:
-
7450*1310*1310mm
-
Tare Weight:
-
7000 Kg
-
Axle Brand:
-
FuWa,BPW,SAF Brand
-
Suspension:
-
Common Mechanical Suspension/Air Suspension
-
Steel Spring:
-
10/10/10 leaf spring suspension
-
Side Beam:
-
18mm
-
OEM/ODM:
-
Available
-
Color:
-
Custom's Requirement
Products Description
The Side curtain semi trailer is a form of the van semi-trailer. The curtain van semi-trailer is mainly used to transport all kinds of pallet goods such as auto parts, beer and beverages. When loading and unloading goods, the curtains on both sides can be quickly opened, which can be used by forklifts. Loading and unloading goods on both sides at the same time, generally within 5 minutes can load or unload the whole truck, is currently one of the fastest loading and unloading cargo transportation tools, at the same time, the car also has the rain and dustproof of the van Features.
Side Curtain trailers can load goods efficiently, not only because multiple forklifts can operate at the same time after the side curtains of the truck are unfolded, but more importantly, the use of standardized pallets to optimize the loading steps, and through the mutual combination of standardized pallets, The utilization rate of the container volume is maximized. In addition, reasonable cargo layout also helps to average vehicle axle loads, which can effectively improve vehicle driving safety while reducing vehicle wear and tear.
|
Curtain Side Semi Trailer
|
|
|
|
Overall Dimension (Lx W x H)(mm)
|
13900*2500*4000 （customized）
|
|
|
Tare Weight
|
7000KG
|
|
|
Loading Weight
|
40000KG
|
|
|
Total Weight
|
50000KG
|
|
|
Axle Brand
|
FuWa、BPW、SAF Brand
|
|
|
Wheelbase
|
7450*1310*1310mm
|
|
|
Suspension system
|
Common Mechanical Suspension/Air Suspension
|
|
|
Steel Spring
|
10/10/10 leaf spring suspension
|
|
|
The material of Main beam
|
The height of the beam is 500mm,
upper plate is14mm down plate is 16mm middle plate is 8mm |
|
|
Side Beam
|
18mm
|
|
|
Platform plate
|
3mm Diamond plate
|
|
|
Curtain Height
|
2000mm
|
|
|
Slider
|
Manual operation
|
|
|
Tire Type
|
8.25R20/8.25R16/11.00R22.5/12.00R22.5/10.00R20/11.00R20/12.00R20/385/65R22.5
|
|
|
Traction Pin
|
50MM or 90MM
|
|
|
Spare Wheel Bracket
|
2 pieces
|
|
|
Tool Box
|
1 Standard
|
|
|
Landing Gear
|
28ton
|
|
|
Painting
|
Color as customer’s requirement
|
|
|
Pictures and configuration information are for reference only.The final product can be made according to specific requirements.
|
|
|
|
Above Information are HUALU Standard Spec.If customer want to change Spec.Please Let us know.
Want to know more details,please contact us directly. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Product Presentation
Both sides are made of soft tarpaulin flexible materials, with guide rails on top and locking structures on the bottom. The curtain can be quickly pulled open during loading and unloading, making it convenient to use forklift pallets for loading and unloading goods, with high loading and unloading efficiency.
Due to the significantly lighter weight of the side curtains compared to the hard side panels, the entire vehicle is 1000kg-1500kg lighter than a box car, with a lighter weight and significantly higher loading capacity
The compartment is completely enclosed, able to prevent rain and dust, and provide all-weather protection for the goods; The volume of the compartment is completely determined, which can effectively prevent overloading and exceeding the limit.
The side of the side curtain trailer is made of curtain fabric, which can be customized and printed with extremely exquisite patterns, which has an excellent promotional effect on the brand image of the transporter.
