Quick Details
-
Brand Name:
-
FS Thermo
-
Product name:
-
solar air conditioner compressor
-
Refrigerant:
-
R134a
-
Name:
-
48V compressor
-
Voltage:
-
48V
-
Compressor type:
-
Hermetic Rotary Compressor
-
Cooling capacity:
-
9000-12000btu
-
Description:
-
solar Air Conditioner
-
Compressor:
-
DC Inverter Rotary Compressor
-
Usage:
-
bldc ac compressor 1 ton air conditioner
Quick Details
-
Type:
-
Refrigeration Compressor
-
Application:
-
Refrigeration Parts
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FS Thermo
-
Product name:
-
solar air conditioner compressor
-
Refrigerant:
-
R134a
-
Name:
-
48V compressor
-
Voltage:
-
48V
-
Compressor type:
-
Hermetic Rotary Compressor
-
Cooling capacity:
-
9000-12000btu
-
Description:
-
solar Air Conditioner
-
Compressor:
-
DC Inverter Rotary Compressor
-
Usage:
-
bldc ac compressor 1 ton air conditioner
bldc ac compressor 1 ton air conditioner
| Application | Base station air conditioner, solar air conditioner |
| Refrigerant | R134a |
| Displacement | 22.0cm³/rev |
| Cooling capacity | 3150W |
| Input power | 940W |
| Model |
Power Supply |
Mount Type |
Disp | ASHARE(7.2℃ | Power | Speed range | Height | Test Condition | |
| Cooling capacity | |||||||||
| cc/rev | W | Btu/h | ASHRAE/T | ||||||
| FSQX014Z12 | 12V | Vertical | 1.4 | 250 | 850 | 92 | 2000-5400 | 78 | 4500 rpm |
| FSQX019Z12 | 12V | Vertical | 1.9 | 300 | 1023 | 130 | 2000-6000 | 78 | 4500 rpm |
| FSQX027Z12 | 12V | Vertical | 2.7 | 410 | 1382 | 145 | 2000-5400 | 146 | 4500 rpm |
| FSQX019Z24 | 24V | Vertical | 1.9 | 310 | 1057 | 118 | 2000-6000 | 78 | 4500 rpm |
| FSQX027Z24 | 24V | Vertical | 2.7 | 460 | 1570 | 195 | 2000-5000 | 138 | 4500 rpm |
| FSQX325Z24 | 24V | Vertical | 3.3 | 550 | 1876 | 212 | 2000-4500 | 140 | 4500 rpm |
| FSQA073Z24 | 24V | Vertical | 7.3 | 1025 | 3500 | 312 | 1800-4500 | 180 | 3600 rpm |
| FSQA088Z24 | 24V | Vertical | 8.8 | 1270 | 4300 | 410 | 2000-4500 | 185 | 3600 rpm |
| FSQA135Z24 | 24V | Vertical | 13.5 | 1950 | 6650 | 965 | 2000-4500 | 208 | 3600 rpm |
| FSQX014Z48 | 48V | Vertical | 1.4 | 252 | 853 | 93 | 2000-5400 | 78 | 4500 rpm |
| FSQX019Z48 | 48V | Vertical | 1.9 | 310 | 1057 | 118 | 2000-6000 | 80 | 4500 rpm |
| FSQA036Z48 | 48V | Vertical | 3.6 | 500 | 1705 | 164 | 1800-4500 | 190 | 3600 rpm |
| FSQA058Z48 | 48V | Horizontal | 5.8 | 620 | 2115 | 204 | 1800-4500 | 123 | 3600 rpm |
| FSQA088Z48 | 48V | Horitontal | 8.8 | 890 | 3035 | 266 | 1800-4500 | 123 | 3600 rpm |
| FSQA120 | 48/72/96V | Vertical | 12.0 | 1625 | 5541 | 525 | 2000-4500 | 200 | 3600 rpm |
| FSQA150Z48 | 48V | Horizontal | 15.0 | 2080 | 7093 | 690 | 1800-4500 | 130 | 3600 rpm |
| WF180HD48 | 48V | Horizontal | 18.0 | 2510 | 8550 | 770 | 1800-4500 | 160 | 3600 rpm |
| WF180HD72 | 72V | Horizontal | 18.0 | 2510 | 8550 | 770 | 1800-4500 | 161 | 3600 rpm |
| WF180HD312 | 312V | Horizontal | 18.0 | 2510 | 8550 | 770 | 1800-4500 | 161 | 3600 rpm |
| WF280HD312 | 312V | Horizontal | 28.0 | 4000 | 13640 | 1200 | 1800-4500 | 161 | 3600 rpm |
Characteristic
1, extremly small
2, high performance
3, high cooling capacity
4, rapid cooling down
5, precise controll of tempreature
6, high COP
7, low energy consumption
8, environmental friendly refrigerant R134A
9, Low noise and vibration
10, High reliability
11, overcurrent protection
12, Wide Evaporating temperature range
13, hybrid power source as DC electrical,battery,solar
14, variable application
