- Product Details
- {{item.text}}
Quick Details
-
Material:
-
aluminum
-
Brand Name:
-
Mitu
-
Model Number:
-
XYM 2000w
-
output voltage and current:
-
24v 50A
-
Maximum Output Power:
-
2000W
-
Place of Origin:
-
shenzhen
-
Product name:
-
XYM 2000W battery pack charger
-
Input Voltage:
-
100-240V-45-65Hz
-
Output Voltage:
-
24V
-
Size:
-
286*159*123
-
Weight:
-
4.5kg
-
Color:
-
Silver
-
Certification:
-
ISO
-
Warranty:
-
1 Year
-
OEM/ODM:
-
Output plug
-
MOQ:
-
1set
Quick Details
-
Type:
-
Electric
-
Port:
-
DC, AC
-
Usage:
-
battery pack
-
Material:
-
aluminum
-
Brand Name:
-
Mitu
-
Model Number:
-
XYM 2000w
-
output voltage and current:
-
24v 50A
-
Maximum Output Power:
-
2000W
-
Place of Origin:
-
shenzhen
-
Product name:
-
XYM 2000W battery pack charger
-
Input Voltage:
-
100-240V-45-65Hz
-
Output Voltage:
-
24V
-
Size:
-
286*159*123
-
Weight:
-
4.5kg
-
Color:
-
Silver
-
Certification:
-
ISO
-
Warranty:
-
1 Year
-
OEM/ODM:
-
Output plug
-
MOQ:
-
1set
Specification

AC input voltage range: 90-264VAC; 45-65Hz
AC input maximum current: 8.5A@220VAC
Power factor: ≥0.99
Machine efficiency: ≥94.0%
Noise: ≤45dB
Protection class: IP67
Net weight: 4.5kg
Working temperature: -30℃-65℃
Storage temperature: -40℃-95℃
Size: 286*159*88


Product Description
Safety
Application of active PFC, LLC and other technologies; reliable hardware protection and voltage and current self-check protection; perfect charging strategy. Make sure the charging process is highly safe.
reliable
The shell adopts an integrated die-casting structure; the inside of the machine adopts a glue filling process; the active cooling fan adopts a long-life, potting structure design. With highly reliable product engineering and years of industry-proven, the charger can adapt to harsh environments.
Features
CNC bus; low-voltage auxiliary 12V; external three-color indicator light; charging lock (the vehicle power system can be locked through the relay dry contact during the charging process). Meet the charging needs of various occasions.
Overheat protection: When the internal temperature of the charger exceeds the internal set value, the charging current will automatically decrease; if the ambient temperature exceeds 65°C, the charger will shut down for protection, and automatically resume charging when the temperature recovers.
Reverse battery connection protection: When the battery is reversely connected, the internal circuit of the charger is disconnected from the battery, which will not damage the charger.
No-load protection: no output when no battery is connected.
Short-circuit protection: When the output is short-circuited, the internal circuit of the charger is disconnected from the battery, and charging can be resumed only when the battery is reconnected after the fault is eliminated. Automatic shutdown when fully charged: automatically shutdown when fully charged.
1
High and low temperature test
2
SMT patch workshop
3
Aging test
4
Auto aging test
5
Let battery curve test
6
Semi finished product test
