Quick Details
-
Model Number:
-
ML4030BC
-
Warranty:
-
12 Months
-
Certification:
-
ALI
-
Weight:
-
730kgs per column
-
Height:
-
2250mm
-
Width:
-
1100mm
-
Length:
-
1350mm
-
Product name:
-
ML4030BC
-
Motor power:
-
3kw*4
-
Application:
-
Truck Workshop
-
Max lifting height:
-
1700mm
Quick Details
-
Lifting Capacity:
-
30T, 30t
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MAXIMA
-
Model Number:
-
ML4030BC
-
Warranty:
-
12 Months
-
Certification:
-
ALI
-
Weight:
-
730kgs per column
-
Height:
-
2250mm
-
Width:
-
1100mm
-
Length:
-
1350mm
-
Product name:
-
ML4030BC
-
Motor power:
-
3kw*4
-
Application:
-
Truck Workshop
-
Max lifting height:
-
1700mm
| Model | ML4022 | ML6033 | ML4030 | ML6045 | ML8060 | ML4034 | ML6051 |
| No. of columns | 4 | 6 | 4 | 6 | 8 | 4 | 6 |
| Capacity per column | 5.5 tons | 7.5 tons | 8.5 tons | ||||
| Total capacity | 22 tons | 33 tons | 30 tons | 45 tons | 60 tons | 34 tons | 51 tons |
| Max. lifting height | 1700mm | ||||||
| Time for lifting/lower | 120s/100s | ||||||
| Lifting system | Hydraulic | ||||||
| Power supply | 208V/220V 3 phase 60Hz; 380V/400V/415V 3 phase 50Hz | ||||||
| Motor power | 2.2Kw per column | ||||||
| Weight | 600kgs per column | ||||||
| Dimension | 2300mm(H)*1100mm(W)*1300mm(L) | ||||||
Battery & charger
Save time for plug-in/off
Operate the lifts anytime & anywhere
No tripping hazard to operators
LCD screen display
Real-time lifting height
Continuously monitored battery condition
Mode type
Multi languages option
Troubleshooting for any fault
Safety
Automatic stop when highest point is reached
Throttle valve & mechanical lock
Automatic stop when either column has 50mm height difference
Advanced synchronization system
The set can go up & down smoothly even if the truck is unevenly loaded to each column Each column has the operation & emergency buttons for easy access.
IP 54 water-proof
CE approved
