Quick Details
-
Panel Size:
-
50.1"
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
SBD Series
-
Pixel Pitch:
-
n/a, N/A
-
Specification:
-
Android, PC or Monitor All available
-
Network connectivity:
-
WiFi/LAN
-
Operating System:
-
Android 8.1
-
Housing Material:
-
cold-rolled steel
-
Memory:
-
8G Nand Flash
-
TF card slot:
-
64 G maximum support
-
Warranty:
-
1year
-
Smartphone App control:
-
yes
-
Server:
-
yes
-
PC management:
-
yes
Quick Details
-
Application:
-
Indoor
-
Brand Name:
-
HKE
-
Color:
-
black
-
Panel Size:
-
50.1"
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
SBD Series
-
Pixel Pitch:
-
n/a, N/A
-
Specification:
-
Android, PC or Monitor All available
-
Network connectivity:
-
WiFi/LAN
-
Operating System:
-
Android 8.1
-
Housing Material:
-
cold-rolled steel
-
Memory:
-
8G Nand Flash
-
TF card slot:
-
64 G maximum support
-
Warranty:
-
1year
-
Smartphone App control:
-
yes
-
Server:
-
yes
-
PC management:
-
yes
|
|
1. Support real-time management and release on mobile, iPad and PC
2. Support remote upgrade of advertising player software version and OTA upgrade 3. Support the advertising machines in the same group can be played synchronously and the synchronization interval is less than 500ms 4. Support the mobile phone to remotely set the properties of the advertising player, control the volume, rotation angle, time zone, turn off and turn on the advertising player 5. Support remote monitoring of the network status, system status and hardware status of the advertising player, and monitor the content of the advertising player 6. Support the needs of multiple forms of rolling subtitles and bullet screens, the font, size and content of subtitles and bullet screens can be edited 7. Scheduling supports multiple priority levels, and supports shim/normal/interrupt/emergency message priority 8. Scheduling supports multiple recurring modes, recurring by day/week/month 9. It can support multiple media such as video/picture/marquee/subtitle/RSS/component/ppt/pdf 10. Support self-built template mobile phone one-key call to modify at any time |
|
|
|
Display parameters
|
Model
|
15.1“ to 88"
|
|
|
|
Panel Type
|
a-Si TFT-LCD
|
|
|
|
Display area
|
1209.6mm(H)x397mm (V)
|
|
|
|
Display Proportion
|
>2：1
|
|
|
|
Resolution
|
1920X630
|
|
|
|
Display Color
|
16.7M
|
|
|
|
Dot Pitch
|
0.210(H)×0.630(V)mm
|
|
|
|
Brightness
|
500CD
|
|
|
|
Contrast
|
2000：1
|
|
|
|
Viewing angle
|
178°
|
|
|
|
Response Time
|
8ms
|
|
|
|
Refresh Rate
|
60Hz
|
|
|
|
Manual Language
|
Chinese/English
|
|
|
|
Video Interface
|
Optional
|
|
|
|
Audio
interface |
Optional
|
|
|
|
Other
|
Optional
|
|
|
|
CPU
|
ARM Cortex-A35 Quad core
|
|
|
|
DDR
|
2GB DDR3
|
|
|
|
Flash
|
16GB EMMC
|
|
|
|
Wifi
|
2.4G WIFI
802.11b : DQPSK, DBPSK, CCK 802.11g/n : 64-QAM,16-QAM, QPSK, BPSK |
|
|
|
Bluetooth
|
N/A
|
|
|
|
Network Card
|
100MB LANX1
|
|
|
|
Interface support
|
TF Card×1/USB×1/Type-c×1
|
|
|
|
System Version
|
Android 8.1
|
|
|
|
Input Voltage
|
～AC 100-240V 50/60Hz
|
|
|
|
Maximum power consumption
|
Please refer to different size specs
|
|
|
|
Standby power consumption
|
≤0.1W（Board only）
|
|
|
Other
|
storage temperature
|
-20--60°
|
|
|
|
Amplifier power
|
2×8W
|
|
|
|
Product Size
|
1247.6×435×46mm
|
|
|
|
Pakage Size
|
Please refer to different size specs
|
|
|
|
Product Weight
|
Please refer to different size specs
|
|
|
|
Remote Control
|
Optional
|
|
|
|
AC power adapter
|
AC 24V/60HZ
|
|
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than 50 units
Q3. Do you have any MOQ limit ?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional for bulk order.
Q5. How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. but we accept logo print only for bulk order.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 year full warranty to all of our products.
