Quick Details
-
Brand Name:
-
GRX
-
Model Number:
-
GRX-100N-10T
-
Place of Origin:
-
Guangdong, China
-
Package:
-
Carton
Quick Details
-
Transmission Rate:
-
10/100Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
2Gbps
-
Brand Name:
-
GRX
-
Model Number:
-
GRX-100N-10T
-
Place of Origin:
-
Guangdong, China
-
Package:
-
Carton
Product Display
Data Parameters
|
Model
|
GRX-100N-10T
|
|
|
Interface Characteristics
|
|
|
|
Fixed Port
|
8*10/100Base-TX PoE ports (Data/Power)
2*10/100Base-TX uplink RJ45 ports (Data) |
|
|
Ethernet Port
|
10/100Base-T(X) auto-sensing, full/half duplex MDI/MDI-X self-adaption
|
|
|
Functional Switch
(EXTEND)
|
Port 1-8support port VLAN and 10M/250m transmission
|
|
|
|
Note: When the switch status changes, the PoE switch must be restarted for the switch function to take effect.
|
|
|
Twisted Pair Transmission
|
10BASE-TX: Cat5 or later UTP(≤250 meters)
100BASE-TX: Cat5 or later UTP(≤100 meters) |
|
|
Chip Parameter
|
|
|
|
Network Management Type
|
Unmanaged
|
|
|
Network Protocol
|
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX
IEEE802.3x |
|
|
Forwarding Mode
|
Store and Forward(Full Wire Speed)
|
|
|
Switching Capacity
|
2Gbps (Non-blocking)
|
|
|
Forwarding
Rate@64byte |
1.488Mpps
|
|
|
MAC
|
2K
|
|
|
Buffer Memory
|
1.25M
|
|
|
Jumbo Frame
|
1536byte
|
|
|
LED Indicator
|
Power:PWR (Green), Network: Link(Yellow), PoE: PoE (Green)
Functional switch: EXTEND (Green) |
|
|
PoE & Power Supply
|
|
|
|
PoE Port
|
Port 1-8 can support 24V PoE
|
|
|
Power Supply Pin
|
Default 4/5 (+), 7/8 (-)
|
|
|
Max Power Per Port
|
24W/15W
|
|
|
Total PWR / Input Voltage
|
120W/ (AC100-240V)
|
|
|
Physical Parameter
|
|
|
|
Operation TEMP/ Humidity
|
-20~+55°C, 5%~90% RH Non condensing
|
|
|
Storage TEMP/ Humidity
|
-40~+75°C, 5%~95% RH Non condensing
|
|
|
Dimension (L*W*H)
|
195*130*40mm
|
|
|
Net /Gross Weight
|
<0.8kg / <1.2kg
|
|
|
Installation
|
Desktop,Wall-mounted, Rack mounted
|
|
