Quick Details
-
Single phase:
-
50Hz
-
Total absorbed power:
-
900W
-
Materials:
-
HDPE,PP,PB,PVDF
-
Dimension(W*D*H):
-
630*700*570
-
Weight(Standards composition):
-
32kg
-
NW/GW:
-
40/60kg
-
Application:
-
Plastic Pipe
Quick Details
-
Place of Origin:
-
China
-
Working range:
-
20-90mm
-
Power supply:
-
220VAC
-
Single phase:
-
50Hz
-
Total absorbed power:
-
900W
-
Materials:
-
HDPE,PP,PB,PVDF
-
Dimension(W*D*H):
-
630*700*570
-
Weight(Standards composition):
-
32kg
-
NW/GW:
-
40/60kg
-
Application:
-
Plastic Pipe
Socket Fusion Machine ---TSC series
1.Accurately control the welding depth of different pipes and fittings.
2.Accurate control the depth that pipe insert fittings.
3.The diameter selector can avoid over-melting caused by excessive force when pipes are inserted into pipes,.
4.Mechanical operation makes each welding interface Standardization,improve welding quality.
Standard composition:
1.Machine body
2.toll kit
3.Heating plate
4.20,25,32,40,50,75,63,90,110,125,140,160mm sockets and spigots
On request:
Pipe support tripod
The complete machine packing in one Plywood Case (1200×1000×870cm, N.W:250kg , G.W:290kg)
-Machine body:1090×620×590cm N.W:100kg
-Milling cutter:600×460×390cm N.W:26kg
-Heating plate:470×50×600cm N.W:21kg
-Hydraulic gearcase:535×315×435cm N.W:13kg
-Support:590×315×650cm N.W:16kg
-Clamp: N.W: 74kg
Applies to the site,a trench connecting PE,PP,PVDF pipes, pipe fittings can also be produced in the workshop.
welding ducts for the transport of water, gas and other fluids under pressure.
We can supply ISO9001-2008, BV ,SGS, CE etc certification.
All kinds of products are regularly conducted pressure-tight blasting test,longitudinal shrinkage rate test, quick stress crack resistance test, tensile test and melt index test, so as to ensure the quality of products totally reach the relevant standards from raw materials to finished products.
