Quick Details
-
Model Number:
-
CMG7000S-B
-
Rated Voltage:
-
230v
-
Rated Current:
-
22A
-
Speed:
-
3200RPM
-
Frequency:
-
50Hz
-
Rated power:
-
5.0KW
-
Max. power:
-
5.5KW
-
Phase:
-
Single
-
Fuel capacity(L):
-
25
-
Engine model:
-
CP190F
-
Fuel Type:
-
Gasoline
-
Noise(dB@7m):
-
75-78
-
N.W/G.W(KG):
-
125/146
-
Package Size(mm):
-
1020*555*785
-
Load Q'TY(20GP/40HQ):
-
40/84
-
Certification:
-
CE
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Cameo
-
Model Number:
-
CMG7000S-B
-
Rated Voltage:
-
230v
-
Rated Current:
-
22A
-
Speed:
-
3200RPM
-
Frequency:
-
50Hz
-
Rated power:
-
5.0KW
-
Max. power:
-
5.5KW
-
Phase:
-
Single
-
Fuel capacity(L):
-
25
-
Engine model:
-
CP190F
-
Fuel Type:
-
Gasoline
-
Noise(dB@7m):
-
75-78
-
N.W/G.W(KG):
-
125/146
-
Package Size(mm):
-
1020*555*785
-
Load Q'TY(20GP/40HQ):
-
40/84
-
Certification:
-
CE
|
Model
|
CMG7000S-B
|
CMG8000S-B
|
CMG9000S-B
|
CMG13000SDE-B
|
|
Frequency(Hz)
|
50
|
50
|
50
|
50
|
|
Rated powe(KW)
|
5.0
|
6.0
|
7.0
|
10.0
|
|
Max.power(KW)
|
5.5
|
6.5
|
7.5
|
11.0
|
|
Voltage(V)
|
230
|
230
|
230
|
230/400
|
|
Phase
|
Single
|
Single
|
Single
|
Three
|
|
Fuel capacity(L)
|
25
|
25
|
25
|
25
|
|
Engine Model
|
CP190F
|
CP192F
|
CP460
|
CP690
|
|
Oil capacity(L)
|
1.1
|
1.1
|
1.1
|
1.65
|
|
Displacement(CC)
|
420
|
439
|
460
|
690
|
|
Cylinder bore(mm)
|
90*66
|
92*69
|
92*69
|
2-78*71
|
|
Start way
|
Electric
|
Electric
|
Electric
|
Electric
|
|
Fuel Type
|
Gasoline
|
Gasoline
|
Gasoline
|
Gasoline
|
|
Noise(dB@7m)
|
75-78
|
75-78
|
75-78
|
75-78
|
|
Package Size(mm)
|
1020*555*785
|
1020*555*785
|
1020*555*785
|
1217*650*933
|
|
N.W/G.W(kg)
|
125/146
|
127/148
|
131/151
|
238/285
|
|
Loading Q'TY(20GP/40HQ)
|
40/84
|
40/84
|
40/84
|
26/54
|
Here is brief introduction of Camel Power as below:
* 20 years' experience in general machine industry.
* the company has its own workshop with an area of more than 50000 square meters and more than 200 employees.
* It has five automatic production lines and advanced online inspection equipment, with an annual production capacity of more than 500,000 units.
* Our products have been exported to nearly 100 countries and regions around the world.
* Main products: generator sets, welding machine, water pump, air compressor and other terminal series
* Now Camel is the China Chamber of Commerce for I / E of Machinery & Electronic products (CCCME) single-cylinder diesel engine branch and China Internal Combustion Engine Industry Association (CICEIA) Agricultural Machinery Branch member unit.
