Quick Details
-
Voltage:
-
380V 50Hz
-
Power:
-
15.8KVA
-
Dimension(L*W*H):
-
700*500*1010mm
-
Weight (KG):
-
176
-
Product name:
-
arc spray gun
-
Input current:
-
AC 22A
-
OCV:
-
DC 20-45 V
-
Voltage adjust class:
-
thick,fine each 3 class total 9class
-
Voltage characteristic:
-
Flat characteristic
-
Output current:
-
DC 300A
-
Load rate:
-
60% (300A)
-
Keywords:
-
Arc Spray Machine
-
Pressure:
-
>=0.6 MPa
-
Usage:
-
arc spray gun
Quick Details
-
Machine Type:
-
Arc Spray Machine, Spray Booths, Painting Equipment, Plc Controller Programmable Logic Controller, Conveying Equipment, Curing oven, Coating Equipment, Anodized Equipment, Sandblasting Machine, Other, arc spray gun
-
Place of Origin:
-
Henan,China(Mainland)
-
Brand Name:
-
Honest
-
Voltage:
-
380V 50Hz
-
Power:
-
15.8KVA
-
Dimension(L*W*H):
-
700*500*1010mm
-
Weight (KG):
-
176
-
Product name:
-
arc spray gun
-
Input current:
-
AC 22A
-
OCV:
-
DC 20-45 V
-
Voltage adjust class:
-
thick,fine each 3 class total 9class
-
Voltage characteristic:
-
Flat characteristic
-
Output current:
-
DC 300A
-
Load rate:
-
60% (300A)
-
Keywords:
-
Arc Spray Machine
-
Pressure:
-
>=0.6 MPa
-
Usage:
-
arc spray gun
Water sandblasting machine/Supersonic arc spraying machine/Aluminum melting machinee
Arc spray machine to melt the metal material by arc that between two pieces of conductive wire, and then send the molten metal atomization to the product surface with high speed. The arc spray machine is consist of power supply, control device, arc spray gun, wire feeding machine and compressed air supply system, etc. It has reliable performance, low failure rate, material select widely, easy to know the spraying process, and coating stable,etc. It is the most widely application of thermal spraying technology currently, widely used in: power plant boiler corrosion wear resistant coating; steel structure spraying zinc aluminum coating to anti-corrosion; ship hydraulic equipment anti-corrosion spray coating,petrochemical tank anti-corrosion spray coating; and repair all kinds of hardware, axial,rolls, iron products spraying zinc and aluminum coating to anti-corrosion ; paper dryer wear repair; printing roller pressure wound repair, etc. It consist of power supply, controal device, arc spray gun, wire feeding machine. Auxiliary equipments: Sand blast machine and air compressor machine
|
Model |
HT- SX- 3 00 |
|
Voltage |
AC 380V 50Hz 3phase |
|
Power |
1 5 .8KVA |
|
Input current |
AC 22A |
|
OCV |
DC 2 0 —45 V |
|
Voltage adjust class |
thick , fine each 3 class total 9class |
|
Voltage characteristic |
Flat characteristic |
|
Output current |
DC 3 00A |
|
Load rate |
60% ( 3 00A ) |
|
Insulation grade |
E |
|
Dimension ( mm ) |
700×500×1010 |
|
Gross Weight |
176 kg |
|
Pressure |
>= 0.6 MPa |
Please feel free to contact us if you need anything in time.
