Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes
Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes
Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes
Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes
Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes
Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes
Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes
Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes

Slew Ring 270x380x35 mm VU 14 0325 Factory Price Slewing Swing Ring Bearing for Small Ship Cranes

FOB Reference Price: Get Latest Price
≥5 Pieces
US $599.99
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Brand Name:
AVE
Model Number:
VU 14 0325
Place of Origin:
Luoyang, China
Equivalent Model:
VU 14 0325, VU140325
Bore Diameter:
270MM
Outer Diameter:
380MM
Height:
35MM
Customized Slew Bearing:
ODM & OEM & OBM Bearing
Bearing Structure:
Four Point Contact Bearing
Gearing:
None Gear
Mounting Hole:
with holes
Rotating Part:
inner ring and / or outer ring
Weight:
12KG

Quick Details

Applicable Industries:
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Robot Maker, Automation System Manufacturer, Robotic Device
Feature:
VU series small slewing bearing
Seals Type:
UU
Brand Name:
AVE
Model Number:
VU 14 0325
Place of Origin:
Luoyang, China
Equivalent Model:
VU 14 0325, VU140325
Bore Diameter:
270MM
Outer Diameter:
380MM
Height:
35MM
Customized Slew Bearing:
ODM & OEM & OBM Bearing
Bearing Structure:
Four Point Contact Bearing
Gearing:
None Gear
Mounting Hole:
with holes
Rotating Part:
inner ring and / or outer ring
Weight:
12KG
Four-point contact ball bearing is radial single row angular contact ball bearings with raceway that is designed to support axial loads in both directions. For a given axial load, a limited radial load can also be beared. Four-point contact bearings are single-row bearings, and therefore require significantly less space in an axial direction than double-row designs.The bearings comprise solid outer rings, split inner rings and ball and cage assemblies with brass or polyamide cages. The two-piece inner rings enable a large complement of balls to be accommodated. The inner ring halves are matched to the particular bearing and must not be interchanged with those of other bearings of the same size. The outer ring with the ball and cage assembly can be mounted separately from the two inner ring halves.

VA SERIES

External Gear Slewing Bearing

VI SERIES

Internal Gear Slewing Bearing

VU SERIES

None Gear Slewing Bearing

Remark: details structure drawing please contact supplier LISA LEE 008618137917388 or lyave@qq.com

Model No.
di (mm)
Da (mm)
H (mm)
Mass (kgs)
VA 140188 V
135
259.36
2 8
7 .5
VA 160235 N
171
318.6
41.5
1 3
VA 160302 N
238
384
5 2.5
1 4
VA 250309 N
2 35
408.4
6 6
29.5
VI 160288 N
216
340
39
1 2
VI 140326 V
250
382
59
18
VI 160420 N
332
486
39
2 3
VU 140179
124.5
234
35
7
VU 200220
138
302
46
16
VU 130225
200
290
24
5.4
VU 200260
191
329
46
15
VU 140325
270
380
35
12
VU 250380
275
485
55
44
VU 200405
336
474
46
25
VU 250433
344
522
55
41
VU 300574
468
680
68
82
VU 360680
565
795
79
120
