- Product Details
- {{item.text}}
Quick Details
-
Type:
-
CCTV Tester
-
Product name:
-
CCTV Camera Tester
-
Support:
-
CVI/ TVI/ AHD up to 8MP
-
Network cable test:
-
YES
-
Screen size:
-
5 inch IPS Touch Screen
-
Resolution:
-
1920*1080
-
Input port:
-
VGA, HD-MI
-
External power supply:
-
DC 12V 1A
-
Battery:
-
Built-in 7.4V Li-ion battery, 3350mAh
-
Warranty:
-
2 Years
-
Delivery time:
-
1-7days
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CAD
-
Model Number:
-
CAD-T4K046
-
Type:
-
CCTV Tester
-
Product name:
-
CCTV Camera Tester
-
Support:
-
CVI/ TVI/ AHD up to 8MP
-
Network cable test:
-
YES
-
Screen size:
-
5 inch IPS Touch Screen
-
Resolution:
-
1920*1080
-
Input port:
-
VGA, HD-MI
-
External power supply:
-
DC 12V 1A
-
Battery:
-
Built-in 7.4V Li-ion battery, 3350mAh
-
Warranty:
-
2 Years
-
Delivery time:
-
1-7days
Products Description
|
Model
|
CAD-T4K046
|
|
Display
|
New 5 inch IPS touch screen, 1920x1152 resolution
|
|
Video Mode
|
CVBS, IP camera test 4k/H.265/H.264,HD Coaxial test, 8MP AHD/TVI/CVI
|
|
Rapid ONVIF
|
Auto log in and display image, create testing report
|
|
Auto HD
|
auto recognize HD coax camera type and resolution
|
|
|
1 channel HDMI input, support 4K 30FPS.
|
|
|
1 channel VGA input, support 1920 x 1200P 60FPS.
|
|
|
4x zoom, to enlarge image, Screen snapshot, record, save, view and record and play back
|
|
Power output
|
12V/3A power; 48V PoE power output, max power 25.5W
|
|
Cable test
|
UTP cable test, RJ45 TDR cable test
|
|
Network test
|
Trace route, Link monitor, DHCP server, port flashing, Ping test
|
|
Wi-Fi
|
Built in WIFI, speeds 150M, display wireless camera image
|
|
Audio test
|
1 channel audio signal input, test whether sound normal.
|
|
Power management
|
Display DC 12V input & output voltage and power in real time
|
|
External power supply
|
DC 12V 1A
|
|
Battery
|
Built-in 7.4V Li-ion battery, 3350mAh
|
|
Rechargeable
|
After charging 3-4 hours, normal working time 5 hours
|
|
Operation setting
|
OSD menu, select your desired language: English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese, Deutsch,
|
|
|
Turkish Portuguese, Czech etc
|
|
Auto off
|
1-30 (mins)
|
|
Working Temperature
|
-10℃---+50℃
|
|
Working Humidity
|
30%-90%
|
|
Dimension/Weight
|
183mm x 110mm x 36.5mm /gross weight 1.5kg
|
