Quick Details
-
Brand Name:
-
JNOD/OEM your logo
-
Model Number:
-
FG55HPD-W
-
Power (W):
-
3500
-
Voltage (V):
-
230
-
Capacity:
-
ENDLESS
-
Contorl:
-
Rotary Stepless Knob/ Sensor Touch Panel
-
Feature:
-
ELCB/ Double Relay / Built In DC Pump
-
Temperature Range:
-
30-55℃
-
Rated Power:
-
3.5kW/ 4.5kW /5.5KW
-
Color:
-
White/ Black
-
WATER PRESSURE:
-
0.02-0.6MPA
-
Certification:
-
EMC CE CB RoHS
-
Heating element:
-
Cast Aluminium Heating Element
-
Voltage phase:
-
220-240V 50/60Hz
Quick Details
-
Warranty:
-
1 Year
-
Application:
-
Hotel, Car, Garage, RV, Commercial, Household
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JNOD/OEM your logo
-
Model Number:
-
FG55HPD-W
-
Power (W):
-
3500
-
Voltage (V):
-
230
-
Capacity:
-
ENDLESS
-
Contorl:
-
Rotary Stepless Knob/ Sensor Touch Panel
-
Feature:
-
ELCB/ Double Relay / Built In DC Pump
-
Temperature Range:
-
30-55℃
-
Rated Power:
-
3.5kW/ 4.5kW /5.5KW
-
Color:
-
White/ Black
-
WATER PRESSURE:
-
0.02-0.6MPA
-
Certification:
-
EMC CE CB RoHS
-
Heating element:
-
Cast Aluminium Heating Element
-
Voltage phase:
-
220-240V 50/60Hz
|
Model NO.
|
FG-HPD
|
|
|
||
|
Voltage & Frequency
|
220-240V 50/60Hz
|
|
|
||
|
Wattage
|
3.5kW
|
4.5kW
|
5.5kW
|
||
|
Max.Ampere Load
|
15.9A
|
20.5A
|
25A
|
||
|
Temperature Setting Range
|
30-55℃ / 86-131℉
|
|
|
||
|
Overheat Protection
|
65℃
|
|
|
||
|
Thermal Cut-off
|
95℃
|
|
|
||
|
Connecting Wires Section
|
2.5mm²
|
|
|
||
|
Water Pressure
|
0.02-0.6MPa
|
|
|
||
|
Safety Class
|
IP25
|
|
|
||
|
Min.water flow to activate
|
1.0 L/min
|
1.2L/min
|
|
||
|
Water Connection
|
G1/2"
|
|
|
||
|
Adjustable Level of DC Pump
|
3 Levels
|
|
|
||
|
Certification
|
CE CB
|
|
|
||
|
Colors
|
Black/ White/ Customized
|
|
|
||
|
Installation
|
Wall Mounted/ Under Sink/ Above Counter/ Concealed
|
|
|
||
|
Service
|
OEM/ ODM/ SKD/ CDK Accepted
|
|
|
||
|
Product Size
|
380*210*89mm
|
|
|
||
|
Feature
|
1. ELCB leakage protection
2. Built-in pressure relief valve & booster pump to increase water pressure
3. Double relay
4. Stepless rotary knob control with indication light
5. IP25 Waterproof
6. Easy wall mounted installation with only 4 screws
7. Die cast aluminum heating element
8. Upside down installation available
|
|
|
||
FAQ
Q1: Are you a manufacturer or trading company?
A: We are professional manufacturer of electric water heater,electric
heating faucet and electric boiler with over 10 years experience.
Q2: What is your sample policy?
A: Our sample fee is refundable,the sample cost can be returned to you
with your bulk order.
Q3: What is the production lead time?
A: For inventory model,the delivery day will be 7-15 days after payment.
For custom model,the delivery time will be according to the purchase
quantity.25-35 working days.
Q4: Will you provide technical promotion support?
A: Of course,we can provide corresponding pictures and videos to you
