Quick Details
-
Measuring Capacitance Range:
-
4nF/40nf/400nF/4uF/40uF/400uF/4mF/10mF
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
UNI-T
-
Model Number:
-
UT39C+
-
Measuring Inductance Range:
-
/
-
Operating Temperature:
-
0℃~40℃
-
Dimensions:
-
175x83x53mm
-
Product Name::
-
Digital Multimeter
-
Display count::
-
4000
-
frequency::
-
10Hz-1MHz
-
Temperature::
-
-40℃~1000℃(-40℉~1832℉)
-
Frequency response::
-
40Hz~400Hz
-
NCV::
-
YES
-
Transistor hFE::
-
YES
-
Continuity test::
-
YES
-
Backlight::
-
YES
-
Data hold::
-
YES
Quick Details
-
Measuring Current Range:
-
400uA/400mA/10A
-
Measuring Voltage Range:
-
400mV/4V/40V/400V/1000V
-
Measuring Resistance Range:
-
400Ω/4000Ω/40kΩ/400kΩ/4MΩ/40MΩ
-
Measuring Capacitance Range:
-
4nF/40nf/400nF/4uF/40uF/400uF/4mF/10mF
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
UNI-T
-
Model Number:
-
UT39C+
-
Measuring Inductance Range:
-
/
-
Operating Temperature:
-
0℃~40℃
-
Dimensions:
-
175x83x53mm
-
Product Name::
-
Digital Multimeter
-
Display count::
-
4000
-
frequency::
-
10Hz-1MHz
-
Temperature::
-
-40℃~1000℃(-40℉~1832℉)
-
Frequency response::
-
40Hz~400Hz
-
NCV::
-
YES
-
Transistor hFE::
-
YES
-
Continuity test::
-
YES
-
Backlight::
-
YES
-
Data hold::
-
YES
Products Description
Product parameter
|
asic skills
|
Range
|
Basic accuracy
|
||
|
|
|
UT39C+
|
||
|
DC voltage (DCV)
|
400.0mV
|
±(0.7%+3)
|
||
|
|
4.000V
|
±(0.5%+2)
|
||
|
|
40.00V
|
±(0.7%+3)
|
||
|
|
400.0V
|
|
||
|
|
1000V
|
|
||
|
AC voltage (ACV)
|
4.000V
|
±(0.7%+2)
|
||
|
|
40.00V
|
±(1.0%+3)
|
||
|
|
400.0V
|
|
||
|
|
750V
|
|
||
|
Alternating current (ACA)
|
40.00mA
|
±(1.0%+2)
|
||
|
|
400.0mA
|
|
||
|
|
10.00A
|
±(1.5%+3)
|
||
|
DC current (DCA)
|
40.00uA
|
±(0.8%+3)
|
||
|
|
400.0uA
|
|
||
|
|
4.000mA
|
|
||
|
|
40.00mA
|
|
||
|
|
400.0mA
|
|
||
|
|
10.00A
|
±(1.2%+5)
|
||
|
Resistance (Ω)
|
400.0Ω
|
±(1.0%+2)
|
||
|
|
4.000kΩ
|
±(0.8%+2)
|
||
|
|
40.00kΩ
|
|
||
|
|
400.0kΩ
|
|
||
|
|
4.000MΩ
|
±(1.0%+2)
|
||
|
|
40.0MΩ
|
±(1.2%±3)
|
||
|
capacitance
|
4.000nF
|
±(4.0%+10)
|
||
|
|
400.0nF
|
±(4.0%+5)
|
||
|
|
|
|
||
|
|
4.000uF
|
|
||
|
|
40.00uF
|
|
||
|
|
400.0uF
|
±10%
|
||
|
|
4.000mF
|
|
||
|
frequency
|
10Hz-1MHz
|
±(0.1%+4)
|
||
|
Celsius temperature (°C)
|
-40~40℃
|
±4℃
|
||
|
|
>40~500℃
|
±(1.0%+4)
|
||
|
|
>500~1000℃
|
±(2.0%+4)
|
||
|
Fahrenheit (°F)
|
-40~104℉
|
±5℉
|
||
|
|
>104~932℉
|
±(1.5%+5)
|
||
|
|
>932~1832℉
|
±(2.5%+5)
|
||
|
special function
|
|
|
||
|
NCV
|
√
|
|
||
|
Transistor
|
√
|
|
||
|
Diode measurement
|
√
|
|
||
|
On-off beep
|
√
|
|
||
|
Low voltage display
|
√
|
|
||
|
Digital retention
|
√
|
|
||
|
Relative value measurement
|
√
|
|
||
|
Automatic shut-down
|
√
|
|
||
|
Backlight
|
√
|
|
||
|
Operating temperature
|
0℃~40℃
|
|
||
|
Safety certification level
|
CAT Ⅱ 1000V/CAT III 600V
|
|
||
|
General characteristics
|
|
|
||
|
Product color
|
Red + gray
|
|
||
|
Product bare metal weight
|
330 grams
|
|
||
|
Product Size
|
175x83x53mm
|
|
||
|
standard packaging
|
Color box, instruction manual
|
|
||
|
Standard number of outer boxes
|
30 units
|
|
||
|
Standard outer box size
|
390×355×355mm
|
|
||
|
Standard outer box gross weight
|
12.75 kg
|
|
||
