Quick Details
-
Model Number:
-
JHG00160
-
Product name:
-
160A 1P 690V NH00 Panel Mount Din Fuse Disconnect
-
Material:
-
PLASTIC
-
Rated voltage:
-
400-690 Vac
-
Rated current:
-
160-630 A
-
Type:
-
NH00/NH1/NH2/NH3
-
Color:
-
Black/White/Blue
-
Size:
-
418*49.6*121mm
-
Application:
-
BUSBAR
-
Rated breaking capacity:
-
50KA/120KA
-
Function level:
-
aR/gR-gG/gL-aM/gM-gtr
Quick Details
-
Breaking Capacity:
-
High
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
JUNKAI ELECTRIC
-
Model Number:
-
JHG00160
-
Product name:
-
160A 1P 690V NH00 Panel Mount Din Fuse Disconnect
-
Material:
-
PLASTIC
-
Rated voltage:
-
400-690 Vac
-
Rated current:
-
160-630 A
-
Type:
-
NH00/NH1/NH2/NH3
-
Color:
-
Black/White/Blue
-
Size:
-
418*49.6*121mm
-
Application:
-
BUSBAR
-
Rated breaking capacity:
-
50KA/120KA
-
Function level:
-
aR/gR-gG/gL-aM/gM-gtr
160A 1P 690V NH00 Panel Mount Din Fuse Disconnect
1.GB 14048.3; IEC60947-3
2.Rated voltage: 400Vac 690Vac ;250-1000Vdc
This fuse disconnecting switch is the first combination of current transformer and fuse switch. It is suitable for rated current 160A-630A and rated frequency 50/60HZ. This series of product modularity, small volume, safe and reliable use, high application in low voltage power distribution cabinet installed capacity density, showing very high economy, safety and contingency, not only has the switch and protection function, but also can be extended to other functions, not only is a kind of closed form is more important it is an intelligent system that is widely used in low voltage cable branch box, box type substation, factories, and other areas, is a trend in the future in the field of distribution.
The products meet the standards: GB14048.3, IEC60947-3
Product features
160A 1P 690V NH00 Panel Mount Din Fuse Disconnect
1. union can be closed and broken at the same time;The split can be made by single phase;
2. the operation is safer, the core is installed in the handle, and can be directly used as contact blade;
3. beautiful and practical, seat and body disassembly convenient, and box installation fast, convenient construction;
4. reduce wiring, easy to increase the loop, increase the use rate of the box;
5. resin glass fiber base, V0 class flame retardant, shell protection level up to IP30;
6. the latest products, the highest market utilization, customized bidding style;
7. the instantaneous breaking operation is up to 100kA, with a load capacity of up to 1.3 times of rated current;
8. It can add fuse monitor, signal switch and remote control module.
160A 1P 690V NH00 Panel Mount Din Fuse Disconnect
1.pls provde more details abt the product you need , so we could confirm the model to our model ASAP
2.The price we provide could be FOB / EXW ,and those price will be provide a the samples order , if the qty you need is big enough
we could discuss more per terms of payment
3.we also could provide OEM service , with your requirements .
4.you could contact with me via email ,skype ,whatapp,and wechat. at any time
160A 1P 690V NH00 Panel Mount Din Fuse Disconnect
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 50% as deposit, and 500% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 5 to 20 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
