High Efficiency
10% greater excitation force than other products in the same category resulting in 16.7% greater production.
Extended Life Time
The use of water wheel type lubrication on the vibratory bearing extends the bearing life up to 5,000 hours.
The engine air filter is raised and the air is filtered twice to protect the engine.
The hydraulic system contains three stage filtration.
Operator Comfort
Cab mounted on vibration damping mounts
Cab temperature control
Operator control forces have been reduce
Safety Features
Rounded bumpers front and rear
Large rear glass and sloped hood for greater visibility
- Product Details
- {{item.text}}
Quick Details
-
Engine Brand:
-
Other
-
Travel Speed:
-
0-11km/h, 0-11km/h
-
Place of Origin:
-
Jiangxi, China, China
-
Brand Name:
-
Top China Brand
-
Dimension(L*W*H):
-
2550*1280*2560mm, 2550*1280*2560mm
-
Drum diameter:
-
1500mm
-
Marketing Type:
-
New Product 2023
-
Model Number:
-
STR30C-8
-
Engine Model:
-
YANMAR
-
Nominal Amplitude:
-
0.5mm
-
Vibration Frequency:
-
55/67Hz
Quick Details
-
Type:
-
Static Roller
-
Power:
-
28.1kw
-
Weight:
-
3TON, 3TON
-
Engine Brand:
-
Other
-
Travel Speed:
-
0-11km/h, 0-11km/h
-
Place of Origin:
-
Jiangxi, China, China
-
Brand Name:
-
Top China Brand
-
Dimension(L*W*H):
-
2550*1280*2560mm, 2550*1280*2560mm
-
Drum diameter:
-
1500mm
-
Marketing Type:
-
New Product 2023
-
Model Number:
-
STR30C-8
-
Engine Model:
-
YANMAR
-
Nominal Amplitude:
-
0.5mm
-
Vibration Frequency:
-
55/67Hz
Product Overview
PRODUCT FEATURE
Specifiction
|
Model
|
STR30C-8
|
|
Weight and Load
|
|
|
Operating Weight
|
3000kg
|
|
Weight at Drum
|
1450kg
|
|
Weight at Rear Axle
|
1550kg
|
|
Compaction Mechanism
|
|
|
Vibration Frequency
|
55/67Hz
|
|
Nominal Amplitude
|
0.5mm
|
|
Centrifugal Force
|
46/28kN
|
|
Drum Width
|
1200mm
|
|
Maneuver Ability
|
|
|
Travel Speed
|
0-11km/h
|
|
Theoretical Gradeability Vibratory
|
30%
|
|
Engine
|
|
|
Engine Model
|
3TNV88-BDTYC
|
|
Rated Power
|
28.1kW
|
