Engine
|
|
|
4 stroke,air cooled gasoline HONDA engine
|
|
|||
Output Power
|
|
|
13HP(9.6KW)
|
|
|||
Pump Performance
|
|
|
400L/min@0.65MPa
600L/min@0.55MPa 1000L/min@0.35MPa |
|
|||
Total Weight
|
|
|
56kg
|
|
|||
Dimensions
|
|
|
565x560x530(mm)
|
|
|||
Cylinders
|
|
|
Single Cylinder
|
|
|||
Fuel Type
|
|
|
unleaded gasoline Min.87 octane
|
|
|||
Fuel Tank Capacity
|
|
|
6.5L
|
|
|||
Fuel System
|
|
|
Carburetor,choke
|
|
|||
Lubrication system
|
|
|
Splash lubrication
|
|
|||
Engine oil capacity
|
|
|
0.9L
|
|
|||
Starter
|
|
|
Recoil/electric starter
|
|
|||
Fuel consumption
|
|
|
3.5L/h
|
|
|||
Pump Specification
|
|
|
Single suction with single stage impeller
|
|
|||
Inlet Diameter
|
|
|
2.5" (65mm)
|
|
|||
Outlet Diameter
|
|
|
2.5"(65mm)
|
|
|||
Number of outlets
|
|
|
1
|
|
|||
Outlet valve ty
|
|
|
Ball Valvee
|
|
|||
Water diversion method
|
|
|
Rotary vane vacuum pump water diversio
|
|
|||
Suction time
|
|
|
≤15s
|
|
|||
Maximum suction depth
|
|
|
9m
|
|
|||
Maximum Water Lift
|
|
|
65m
|
|
|||
Rated Flow
|
|
|
600L/min
|
|
|||
Rated Pressure
|
|
|
0.55MPa
|
|
